Запчасти Komatsu 4D95S-W-1G-AS ТОПЛ. НАСОС (ПОДКАЧИВАЮЩ. НАСОС) ТОПЛИВН. СИСТЕМА

Схема запчастей Komatsu 4D95S-W-1G-AS - ТОПЛ. НАСОС (ПОДКАЧИВАЮЩ. НАСОС) ТОПЛИВН. СИСТЕМА
1
2
3
4
5
6
7
8
9
10
10
11
11
12
13
13
14
15
16
17
18
19
19
19
20
1
2
3
4
5
6
7
8
9
10
10
11
11
12
13
13
14
15
16
17
18
19
19
19
20
1
2
3
4
5
6
7
8
9
10
10
11
11
12
13
13
14
15
16
17
18
19
19
19
20

Артикул

Название

Примечание

Количество

|$0

6202-72-1231

INJECTION PUMP ASS'Y

SN: .-UP

1шт.

|$1

0

INJECTION PUMP ASS'Y

SN: 23318-.

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0453 TO 0482.

-1шт.

|$$4

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$4

DK105220-5700

FEED PUMP ASS'Y

SN: .-UP

1шт.

|$5

DK105220-5360

FEED PUMP ASS'Y

SN: 23318-.

1шт.

1

DK152003-1020

HOUSING

SN: 23318-UP

1шт.

2

DK152100-1120

PISTON

SN: 23318-UP

1шт.

3

DK152102-1600

SPRING

SN: 23318-UP

1шт.

4

DK152105-1600

PLUG

SN: .-UP

1шт.

4

DK152105-0200

PLUG

SN: 23318-.

1шт.

5

DK029332-6030

GASKET

SN: 23318-UP

1шт.

6

DK152111-2820

TAPPET ASS'Y

SN: 23318-UP

1шт.

7

DK152112-0100

ROLLER

SN: 23318-UP

1шт.

8

DK152113-0700

PIN

SN: 23318-UP

1шт.

9

DK152114-0400

GUIDE

SN: 23318-UP

2шт.

10

DK152115-0500

VALVE

SN: 23318-UP

2шт.

11

DK152116-0200

SPRING

SN: 23318-UP

2шт.

12

DK152118-0900

ADAPTER

SN: 23318-UP

1шт.

13

DK029631-6060

O-RING

SN: 23318-UP

2шт.

14

DK152121-0200

RING,SNAP

SN: 23318-UP

1шт.

15

DK152200-5420

PUMP,PRIMING

SN: 23318-UP

1шт.

16

DK152300-5920

BOLT,JOINT

SN: 23318-UP

1шт.

17

DK029731-4680

BOLT,JOINT

SN: 23318-UP

1шт.

18

DK152350-6720

PIPE

SN: 23318-UP

1шт.

19

DK029341-4130

GASKET

SN: 23318-UP

4шт.

20

DK152320-0100

COVER

SN: 23318-UP

1шт.

|$0

6202-72-1231

INJECTION PUMP ASS'Y

SN: .-UP

1шт.

|$1

0

INJECTION PUMP ASS'Y

SN: 23318-.

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0453 TO 0482.

-1шт.

|$$4

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$4

DK105220-5700

FEED PUMP ASS'Y

SN: .-UP

1шт.

|$5

DK105220-5360

FEED PUMP ASS'Y

SN: 23318-.

1шт.

1

DK152003-1020

HOUSING

SN: 23318-UP

1шт.

2

DK152100-1120

PISTON

SN: 23318-UP

1шт.

3

DK152102-1600

SPRING

SN: 23318-UP

1шт.

4

DK152105-1600

PLUG

SN: .-UP

1шт.

4

DK152105-0200

PLUG

SN: 23318-.

1шт.

5

DK029332-6030

GASKET

SN: 23318-UP

1шт.

6

DK152111-2820

TAPPET ASS'Y

SN: 23318-UP

1шт.

7

DK152112-0100

ROLLER

SN: 23318-UP

1шт.

8

DK152113-0700

PIN

SN: 23318-UP

1шт.

9

DK152114-0400

GUIDE

SN: 23318-UP

2шт.

10

DK152115-0500

VALVE

SN: 23318-UP

2шт.

11

DK152116-0200

SPRING

SN: 23318-UP

2шт.

12

DK152118-0900

ADAPTER

SN: 23318-UP

1шт.

13

DK029631-6060

O-RING

SN: 23318-UP

2шт.

14

DK152121-0200

RING,SNAP

SN: 23318-UP

1шт.

15

DK152200-5420

PUMP,PRIMING

SN: 23318-UP

1шт.

16

DK152300-5920

BOLT,JOINT

SN: 23318-UP

1шт.

17

DK029731-4680

BOLT,JOINT

SN: 23318-UP

1шт.

18

DK152350-6720

PIPE

SN: 23318-UP

1шт.

19

DK029341-4130

GASKET

SN: 23318-UP

4шт.

20

DK152320-0100

COVER

SN: 23318-UP

1шт.

|$0

6202-72-1231

INJECTION PUMP ASS'Y

|$1

6202-72-1230

INJECTION PUMP ASS'Y

|$4

DK105220-5700

FEED PUMP ASS'Y

|$5

DK105220-5360

FEED PUMP ASS'Y

1

DK152003-1020

HOUSING

2

DK152100-1120

PISTON

3

DK152102-1600

SPRING

4

DK152105-1600

PLUG

4

DK152105-0200

PLUG

5

DK029332-6030

GASKET

6

DK152111-2820

TAPPET ASS'Y

7

DK152112-0100

ROLLER

8

DK152113-0700

PIN

9

DK152114-0400

GUIDE

10

DK152115-0500

VALVE

11

DK152116-0200

SPRING

12

DK152118-0900

ADAPTER

13

DK029631-6060

O-RING

14

DK152121-0200

RING,SNAP

15

DK152200-5420

PUMP,PRIMING

16

DK152300-5920

BOLT,JOINT

17

DK029731-4680

BOLT,JOINT

18

DK152350-6720

PIPE

19

DK029341-4130

GASKET

20

DK152320-0100

COVER

Выбрано товаров: 79
