Запчасти Komatsu 4D95S-W-1G-AS ТОПЛ. НАСОС (РЕГУЛЯТОР) (/) ТОПЛИВН. СИСТЕМА

Схема запчастей Komatsu 4D95S-W-1G-AS - ТОПЛ. НАСОС (РЕГУЛЯТОР) (/) ТОПЛИВН. СИСТЕМА
1
2
3
4
5
5
6
7
8
9
10
11
12
13
14
15
16
16
17
18
19
20
20
21
21
22
23
24
25
26
27
28
29
30
31
32
33
34
34
35
36
1
2
3
4
5
5
6
7
8
9
10
11
12
13
14
15
16
16
17
18
19
20
20
21
21
22
23
24
25
26
27
28
29
30
31
32
33
34
34
35
36
1
2
3
4
5
5
6
7
8
9
10
11
12
13
14
15
16
16
17
18
19
20
20
21
21
22
23
24
25
26
27
28
29
30
31
32
33
34
34
35
36

Артикул

Название

Примечание

Количество

|$0

6202-72-1231

INJECTION PUMP ASS'Y

SN: .-UP

1шт.

|$1

0

INJECTION PUMP ASS'Y

SN: 23318-.

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0453 TO 0482.

-1шт.

|$$4

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$4

DK105400-7010

GOVERNOR ASS'Y

SN: .-UP

1шт.

|$5

DK105400-4661

GOVERNOR ASS'Y

SN: 23318-.

1шт.

|$$7

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0463 AND 0464.

-1шт.

1

DK154011-0100

NUT,LOCK

SN: 23318-UP

1шт.

2

DK154500-2020

COVER

SN: 23318-UP

1шт.

3

DK154031-3000

SCREW

SN: 23318-UP

1шт.

4

DK139206-0600

NUT

SN: .-UP

1шт.

4

DK029240-6010

NUT

SN: 23318-.

1шт.

5

DK154036-0300

PLUG

SN: 23318-UP

2шт.

6

DK020106-5040

BOLT

SN: 23318-UP

2шт.

7

DK154010-0300

SCREW

SN: 23318-UP

1шт.

8

DK020106-3840

BOLT

SN: 23318-UP

4шт.

9

DK154063-5100

COVER

SN: 23318-UP

1шт.

10

DK029020-6260

BOLT

SN: 23318-UP

2шт.

11

DK020006-2040

BOLT

SN: 23318-UP

1шт.

12

DK020006-1640

BOLT

SN: 23318-UP

1шт.

13

DK154150-6400

SPRING,GOVERNOR

SN: 23318-UP

1шт.

14

DK154158-1320

CAPSULE,SPRING

SN: 23318-UP

1шт.

15

DK154011-1700

NUT

SN: 23318-UP

1шт.

16

DK026512-1540

GASKET

SN: 23318-UP

2шт.

17

DK154159-1200

NUT,CAP

SN: 23318-UP

1шт.

18

DK154200-7020

LEVER ASS'Y,SWIVEL

SN: .-UP

1шт.

18

DK154200-0220

LEVER ASS'Y,SWIVEL

SN: 23318-.

1шт.

19

DK154204-3000

BUSHING

SN: .-UP

1шт.

19

DK154204-1900

BUSHING

SN: 23318-.

1шт.

20

DK029631-8020

O-RING

SN: 23318-UP

2шт.

21

DK016010-1640

RING,SNAP

SN: 23318-UP

2шт.

22

DK139611-0000

SEAL,OIL

SN: 23318-UP

1шт.

23

DK139411-0000

SHIM, 0.40MM

SN: 23318-UP

1шт.

24

DK029311-1090

SHIM, 0.30MM

SN: 23318-UP

-2шт.

25

DK154204-3100

BUSHING

SN: .-UP

1шт.

25

DK154204-1900

BUSHING

SN: 23318-.

1шт.

26

DK029141-7010

PLUG

SN: 23318-.

1шт.

27

DK025803-1310

KEY, 13MM

SN: 23318-UP

1шт.

28

DK154206-2800

COLLAR

SN: 23318-UP

1шт.

29

DK154206-0200

WASHER, 1.0MM

SN: 23318-UP

-2шт.

30

DK154237-0100

PIN

SN: 23318-UP

1шт.

31

DK154342-2320

LEVER

SN: 23318-UP

1шт.

32

DK154350-7800

GASKET

SN: 23318-UP

1шт.

33

DK029635-2020

O-RING

SN: 23318-UP

1шт.

34

DK026506-1040

GASKET

SN: 23318-UP

2шт.

35

DK154035-1600

NUT,CAP

SN: 23318-UP

1шт.

36

DK154358-7200

BRACKET

SN: 23318-UP

1шт.

|$0

6202-72-1231

INJECTION PUMP ASS'Y

SN: .-UP

1шт.

|$1

0

INJECTION PUMP ASS'Y

SN: 23318-.

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0453 TO 0482.

-1шт.

|$$4

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$4

DK105400-7010

GOVERNOR ASS'Y

SN: .-UP

1шт.

|$5

DK105400-4661

GOVERNOR ASS'Y

SN: 23318-.

1шт.

|$$7

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0463 AND 0464.

-1шт.

1

DK154011-0100

NUT,LOCK

SN: 23318-UP

1шт.

2

DK154500-2020

COVER

SN: 23318-UP

1шт.

3

DK154031-3000

SCREW

SN: 23318-UP

1шт.

4

DK139206-0600

NUT

SN: .-UP

1шт.

4

DK029240-6010

NUT

SN: 23318-.

1шт.

5

DK154036-0300

PLUG

SN: 23318-UP

2шт.

6

DK020106-5040

BOLT

SN: 23318-UP

2шт.

7

DK154010-0300

SCREW

SN: 23318-UP

1шт.

8

DK020106-3840

BOLT

SN: 23318-UP

4шт.

9

DK154063-5100

COVER

SN: 23318-UP

1шт.

10

DK029020-6260

BOLT

SN: 23318-UP

2шт.

11

DK020006-2040

BOLT

SN: 23318-UP

1шт.

12

DK020006-1640

BOLT

SN: 23318-UP

1шт.

13

DK154150-6400

SPRING,GOVERNOR

SN: 23318-UP

1шт.

14

DK154158-1320

CAPSULE,SPRING

SN: 23318-UP

1шт.

15

DK154011-1700

NUT

SN: 23318-UP

1шт.

16

DK026512-1540

GASKET

SN: 23318-UP

2шт.

17

DK154159-1200

NUT,CAP

SN: 23318-UP

1шт.

18

DK154200-7020

LEVER ASS'Y,SWIVEL

SN: .-UP

1шт.

18

DK154200-0220

LEVER ASS'Y,SWIVEL

SN: 23318-.

1шт.

19

DK154204-3000

BUSHING

SN: .-UP

1шт.

19

DK154204-1900

BUSHING

SN: 23318-.

1шт.

20

DK029631-8020

O-RING

SN: 23318-UP

2шт.

21

DK016010-1640

RING,SNAP

SN: 23318-UP

2шт.

22

DK139611-0000

SEAL,OIL

SN: 23318-UP

1шт.

23

DK139411-0000

SHIM, 0.40MM

SN: 23318-UP

1шт.

24

DK029311-1090

SHIM, 0.30MM

SN: 23318-UP

-2шт.

25

DK154204-3100

BUSHING

SN: .-UP

1шт.

25

DK154204-1900

BUSHING

SN: 23318-.

1шт.

26

DK029141-7010

PLUG

SN: 23318-.

1шт.

27

DK025803-1310

KEY, 13MM

SN: 23318-UP

1шт.

28

DK154206-2800

COLLAR

SN: 23318-UP

1шт.

29

DK154206-0200

WASHER, 1.0MM

SN: 23318-UP

-2шт.

30

DK154237-0100

PIN

SN: 23318-UP

1шт.

31

DK154342-2320

LEVER

SN: 23318-UP

1шт.

32

DK154350-7800

GASKET

SN: 23318-UP

1шт.

33

DK029635-2020

O-RING

SN: 23318-UP

1шт.

34

DK026506-1040

GASKET

SN: 23318-UP

2шт.

35

DK154035-1600

NUT,CAP

SN: 23318-UP

1шт.

36

DK154358-7200

BRACKET

SN: 23318-UP

1шт.

|$0

6202-72-1231

INJECTION PUMP ASS'Y

|$1

6202-72-1230

INJECTION PUMP ASS'Y

|$4

DK105400-7010

GOVERNOR ASS'Y

|$5

DK105400-4661

GOVERNOR ASS'Y

1

DK154011-0100

NUT,LOCK

2

DK154500-2020

COVER

3

DK154031-3000

SCREW

4

DK139206-0600

NUT

4

DK029240-6010

NUT

5

DK154036-0300

PLUG

6

DK020106-5040

BOLT

7

DK154010-0300

SCREW

8

DK020106-3840

BOLT

9

DK154063-5100

COVER

10

DK029020-6260

BOLT

11

DK020006-2040

BOLT

12

DK020006-1640

BOLT

13

DK154150-6400

SPRING,GOVERNOR

14

DK154158-1320

CAPSULE,SPRING

15

DK154011-1700

NUT

16

DK026512-1540

GASKET

17

DK154159-1200

NUT,CAP

18

DK154200-7020

LEVER ASS'Y,SWIVEL

18

DK154200-0220

LEVER ASS'Y,SWIVEL

19

DK154204-3000

BUSHING

19

DK154204-1900

BUSHING

20

DK029631-8020

O-RING

21

DK016010-1640

RING,SNAP

22

DK139611-0000

SEAL,OIL

23

DK139411-0000

SHIM, 0.40MM

24

DK029311-1090

SHIM, 0.30MM

25

DK154204-3100

BUSHING

25

DK154204-1900

BUSHING

26

DK029141-7010

PLUG

27

DK025803-1310

KEY, 13MM

28

DK154206-2800

COLLAR

29

DK154206-0200

WASHER, 1.0MM

30

DK154237-0100

PIN

31

DK154342-2320

LEVER

32

DK154350-7800

GASKET

33

DK029635-2020

O-RING

34

DK026506-1040

GASKET

35

DK154035-1600

NUT,CAP

36

DK154358-7200

BRACKET

Выбрано товаров: 138
