Артикул
Название
Примечание
Количество
|1
104-15-32032
TRANSMISSION ASS'Y
SN: 62534-62685
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A2 TO F2320-63A2.
-1шт.
|1
104-15-32090
TRANSMISSION ASS'Y
SN: 62534-UP
1шт.
|$$4
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO 59A0¤ 60A3¤ AND 61A2 TO 63A2.
-1шт.
|1
104-15-41010
TRANSMISSION ASS'Y
SN: 62686-UP
1шт.
|$$6
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A2 TO F2320-63A2.
-1шт.
|1
104-15-00550
HOUSING ASS'Y,2ND
SN: 62534-UP
1шт.
1
0
HOUSING
SN: 62534-UP
1шт.
2
113-15-25490
PLUG
SN: 62534-UP
1шт.
4
113-15-22771
PISTON,2ND
SN: 62534-UP
1шт.
6
103-15-31250
BOLT
SN: 62534-UP
4шт.
7
362-15-11270
PIN
SN: 62534-UP
5шт.
8
104-15-32310
CARRIER
SN: 62534-UP
1шт.
9
104-15-32420
GEAR
SN: 62534-UP
3шт.
10
104-15-32560
WASHER
SN: 62534-UP
6шт.
11
104-15-39420
BEARING,NEEDLE
SN: 62534-UP
3шт.
12
104-15-32510
SHAFT
SN: 62534-UP
3шт.
13
113-15-29560
PIN,SPRING
SN: 62534-UP
3шт.
14
104-15-32270
HUB
SN: 62534-UP
1шт.
Выбрано товаров: 21
