Артикул
Название
Примечание
Количество
|1
104-15-32032
TRANSMISSION ASS'Y
SN: 62534-62685
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A2 TO F2320-63A2.
-1шт.
|1
104-15-32090
TRANSMISSION ASS'Y
SN: 62534-UP
1шт.
|$$4
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO 59A0¤ 60A3¤ AND 61A2 TO 63A2.
-1шт.
|1
104-15-41010
TRANSMISSION ASS'Y
SN: 62686-UP
1шт.
|$$6
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A2 TO F2320-63A2.
-1шт.
1
113-15-21290
PIN
SN: 62534-UP
2шт.
5
07018-20954
RING
SN: 62534-UP
2шт.
|7
104-15-00151
HOUSING ASS'Y,FORWARD AND 3RD
SN: 62534-UP
1шт.
7
0
HOUSING
SN: 62534-UP
1шт.
11
103-15-22740
PISTON,FORWARD
SN: 62534-UP
1шт.
12
103-15-22750
PISTON,3RD
SN: 62534-UP
1шт.
14
103-15-29260
SEAL,RING (K1)
SN: 62534-UP
1шт.
17
113-15-21290
PIN
SN: 62534-UP
2шт.
18
104-15-31170
PLATE
SN: 62534-UP
1шт.
19
125-15-11230
PLUG
SN: 62534-UP
1шт.
Выбрано товаров: 26
