Артикул
Название
Примечание
Количество
|$3
104-15-32090
TRANSMISSION ASS'Y,(FOR 2 LEVER STEERING)
SN: 83001-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO 59A0, 60A3, AND 61A2 TO 63A2.
-1шт.
|$5
104-15-41011
TRANSMISSION ASS'Y
SN: 83001-UP
1шт.
|$6
0
TRANSMISSION ASS'Y,(FOR MONO LEVER STEERING)
SN: (83001-83889)
1шт.
|$$5
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F2320-51A1 TO F2320-63A1.
-1шт.
1
113-15-24810
HOUSING
SN: 83001-UP
1шт.
2
113-15-24820
CASE
SN: 83001-UP
1шт.
3
113-15-34830
BRACKET
SN: 83001-UP
1шт.
4
113-15-24840
GEAR
SN: 83001-UP
1шт.
5
113-15-24850
GEAR
SN: 83001-UP
1шт.
6
113-15-29420
BEARING,NEEDLE
SN: 83001-UP
2шт.
7
113-15-29460
BEARING,NEEDLE
SN: 83001-UP
2шт.
8
113-15-24870
BOLT
SN: 83001-UP
1шт.
11
113-15-24880
PIN
SN: 83001-UP
1шт.
14
113-15-24860
GASKET (K1)
SN: 83001-UP
1шт.
15
01010-80855
BOLT
SN: 83001-UP
7шт.
Выбрано товаров: 22
