Артикул
Название
Примечание
Количество
|$2
103-15-00910
TRANSMISSION ASS'Y,(FOR 2 LEVER STEERING)
SN: 90001-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO 56A0, 57A1, 58A0, 59A0, 60A1 AND 61A0, 62A1, 63A0.
-1шт.
|$4
103-15-41010
TRANSMISSION ASS'Y,(FOR MONO LEVER STEERING)
SN: 90001-UP
1шт.
|$$4
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO 59A0, 60A4, 61A0, AND 62A4, 63A0.
-1шт.
|$7
103-15-00641
HOUSING ASS'Y,FORWARD AND 2ND
SN: 90001-UP
1шт.
1
0
HOUSING
SN: 90001-UP
1шт.
6
362-15-12740
PISTON,FORWARD
SN: 90001-UP
1шт.
9
362-15-12750
PISTON,2ND
SN: 90001-UP
1шт.
12
362-15-12720
PLATE
SN: 90001-UP
2шт.
13
113-15-21290
PIN,DOWEL
SN: 90001-UP
2шт.
14
103-15-32910
SPRING
SN: 90001-UP
10шт.
15
103-15-32810
GUIDE
SN: 90001-UP
5шт.
16
362-15-12820
SPACER
SN: 90001-UP
5шт.
17
103-15-31170
PLATE
SN: 90001-UP
1шт.
18
125-15-11230
PLUG
SN: 90001-UP
1шт.
Выбрано товаров: 23
