Артикул
Название
Примечание
Количество
|1
103-15-00910
TRANSMISSION ASS'Y,(FOR 2 LEVER STEERING)
SN: 83001-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO 56A0¤ 57A1¤ 58A0¤ 59A0¤ 60A1 AND 61A0¤ 62A1¤ 63A0.
-1шт.
|1
103-15-41010
TRANSMISSION ASS'Y,(FOR MONO LEVER STEERING)
SN: 83001-UP
1шт.
|$$4
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO 59A0¤ 60A4¤ 61A0¤ AND 62A4¤ 63A0.
-1шт.
|1
103-15-00651
HOUSING ASS'Y,REVERSE
SN: 83001-UP
1шт.
1
0
HOUSING
SN: 83001-UP
1шт.
5
362-15-12750
PISTON,REVERSE
SN: 83001-UP
1шт.
9
103-15-31260
BOLT
SN: 83001-UP
5шт.
10
113-15-21260
WASHER
SN: 83001-UP
5шт.
12
362-15-11270
PIN
SN: 83001-UP
5шт.
16
103-15-32211
GEAR
SN: 83001-UP
1шт.
17
103-15-39550
RING,SNAP
SN: 83001-UP
4шт.
Выбрано товаров: 22
