Артикул
Название
Примечание
Количество
|$2
103-15-41010
TRANSMISSION ASS'Y,(FOR 2 LEVER STEERING)
SN: 83001-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO 59A0, 60A4, 61A0, AND 62A4, 63A0.
-1шт.
|$4
103-15-00910
TRANSMISSION ASS'Y,(FOR MONO LEVER STEERING)
SN: 83001-UP
1шт.
|$$4
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO 56A0, 57A1, 58A0, 59A0, 60A1 AND 61A0, 62A1, 63A0.
-1шт.
|$10
103-15-00710
VALVE ASS'Y
SN: 83001-UP
1шт.
|$11
103-15-00740
SEAT ASS'Y
SN: 83001-UP
1шт.
1
103-15-35130
SEAT
SN: 83001-UP
1шт.
3
104-15-25110
BODY
SN: 83001-UP
1шт.
4
103-15-35140
GASKET (K2)
SN: 83001-UP
1шт.
8
103-15-25350
PLATE
SN: 83001-UP
2шт.
11
361-15-15321
SPOOL
SN: 83001-UP
1шт.
12
103-15-35220
VALVE
SN: 83001-UP
1шт.
13
103-15-35251
SPRING
SN: 83001-UP
1шт.
14
103-15-35260
SPRING
SN: 83001-UP
1шт.
15
104-15-25210
SPOOL,MODULATING
SN: 83001-UP
1шт.
19
113-15-25270
SHIM, 0.2MM (K2)
SN: 83001-UP
2шт.
21
104-15-25340
STOPPER
SN: 83001-UP
2шт.
25
124-15-55390
STOPPER (K2)
SN: 83001-UP
1шт.
26
103-15-35910
GASKET (K2)
SN: 83001-UP
1шт.
Выбрано товаров: 39
