Артикул
Название
Примечание
Количество
|$2
103-15-00910
TRANSMISSION ASS'Y,(FOR 2 LEVER STEERING)
SN: 83001-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO 56A0, 57A1, 58A0, 59A0, 60A1 AND 61A0, 62A1, 63A0.
-1шт.
|$4
103-15-41010
TRANSMISSION ASS'Y,(FOR MONO LEVER STEERING)
SN: 83001-UP
1шт.
|$$4
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO 59A0, 60A4, 61A0, AND 62A4, 63A0.
-1шт.
1
103-15-32321
CARRIER
SN: 83001-UP
1шт.
2
103-15-32370
PLATE
SN: 83001-UP
1шт.
5
103-15-32521
SHAFT
SN: 83001-UP
3шт.
6
125-15-11230
PLUG
SN: 83001-UP
3шт.
7
103-15-32411
GEAR
SN: 83001-UP
6шт.
8
362-15-19410
BEARING
SN: 83001-UP
6шт.
9
113-15-32560
WASHER
SN: 83001-UP
12шт.
10
04025-00312
PIN
SN: 83001-UP
3шт.
12
362-15-19520
RING,SNAP
SN: 83001-UP
1шт.
13
103-15-32630
GEAR,RING
SN: 83001-UP
1шт.
14
103-15-32231
GEAR
SN: 83001-UP
1шт.
17
103-15-32241
GEAR
SN: 83001-UP
1шт.
Выбрано товаров: 21
