Артикул
Название
Примечание
Количество
|$$1
SERIAL NO. 80199 INDICATES D21A-7. THE OTHER MACHINES ARE AS FOLLOWS.
-1шт.
|$$2
D20A-7 = 80089
-1шт.
|$$3
D20A-7B = 80060
-1шт.
|$$4
D21A-7B = 80143
-1шт.
|1
103-15-00612
TRANSMISSION ASS'Y
SN: 78604-80227
1шт.
|$$6
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO F2320-63A0.
-1шт.
|1
103-15-00910
TRANSMISSION ASS'Y
SN: 78604-UP
1шт.
|$$8
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO 56A0¤ 57A1¤ 58A0¤ 59A0¤ 60A1 AND 61A0¤ 62A1¤ 63A0.
-1шт.
|1
103-15-41010
TRANSMISSION ASS'Y
SN: 80228-UP
1шт.
|$$10
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO 59A0¤ 60A4¤ 61A0¤ AND 62A4¤ 63A0.
-1шт.
|1
103-15-00641
HOUSING ASS'Y,FORWARD AND 2ND
SN: 78604-UP
1шт.
1
0
HOUSING
SN: 78604-UP
1шт.
6
362-15-12740
PISTON,FORWARD
SN: 78604-UP
1шт.
9
362-15-12750
PISTON,2ND
SN: 78604-UP
1шт.
12
362-15-12720
PLATE
SN: 78604-UP
2шт.
13
113-15-21290
PIN,DOWEL
SN: 78604-UP
2шт.
14
103-15-32910
SPRING
SN: 78604-UP
10шт.
15
103-15-32810
GUIDE
SN: 78604-UP
5шт.
16
362-15-12820
SPACER
SN: 78604-UP
5шт.
17
103-15-31170
PLATE
SN: 78604-UP
1шт.
18
125-15-11230
PLUG
SN: 78604-UP
1шт.
Выбрано товаров: 29
