Артикул
Название
Примечание
Количество
|$$1
SERIAL NO. 80199 INDICATES D21A-7. THE OTHER MACHINES ARE AS FOLLOWS.
-1шт.
|$$2
D20A-7 = 80089
-1шт.
|$$3
D20A-7B = 80060
-1шт.
|$$4
D21A-7B = 80143
-1шт.
|1
103-15-00612
TRANSMISSION ASS'Y
SN: 78604-80227
1шт.
|$$6
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO F2320-63A0.
-1шт.
|1
103-15-00910
TRANSMISSION ASS'Y
SN: 78604-UP
1шт.
|$$8
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO 56A0¤ 57A1¤ 58A0¤ 59A0¤ 60A1 AND 61A0¤ 62A1¤ 63A0.
-1шт.
|1
103-15-41010
TRANSMISSION ASS'Y
SN: 80228-UP
1шт.
|$$10
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO 59A0¤ 60A4¤ 61A0¤ AND 62A4¤ 63A0.
-1шт.
|1
103-15-00630
HOUSING ASS'Y,1ST
SN: 78604-UP
1шт.
1
0
HOUSING
SN: 78604-UP
1шт.
3
362-15-12750
PISTON,1ST
SN: 78604-UP
1шт.
6
07011-10050
SEAL
SN: 78604-UP
1шт.
7
06001-06008
BEARING
SN: 78604-UP
1шт.
11
362-15-12720
PLATE
SN: 78604-UP
1шт.
12
362-15-12720
PLATE
SN: 78604-UP
1шт.
13
362-15-12730
PLATE
SN: 78604-UP
11шт.
14
103-15-32711
DISC
SN: 78604-UP
11шт.
16
113-15-21290
PIN
SN: 78604-UP
2шт.
17
103-15-31150
PLATE
SN: 78604-UP
1шт.
Выбрано товаров: 28
