Артикул
Название
Примечание
Количество
|1
6202-72-1211
INJECTION PUMP ASS'Y
SN: .-UP
1шт.
|1
0
INJECTION PUMP ASS'Y
SN: 23318-.
1шт.
|$$3
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.
-1шт.
|$$4
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK105220-5360
FEED PUMP ASS'Y
SN: 23318-.
1шт.
1
DK152003-1020
HOUSING
SN: 23318-UP
1шт.
2
DK152100-1120
PISTON
SN: 23318-UP
1шт.
4
DK152105-1600
PLUG
SN: .-UP
1шт.
|4
DK152105-0200
PLUG
SN: 23318-.
1шт.
5
DK029332-6030
GASKET
SN: 23318-UP
1шт.
6
DK152111-2820
TAPPET ASS'Y
SN: 23318-UP
1шт.
7
DK152112-0100
ROLLER
SN: 23318-UP
1шт.
8
DK152113-0700
PIN
SN: 23318-UP
1шт.
9
DK152114-0400
GUIDE
SN: 23318-UP
2шт.
10
DK152115-0500
VALVE
SN: 23318-UP
2шт.
12
DK152118-0900
ADAPTER
SN: 23318-UP
1шт.
14
DK152121-0200
RING,SNAP
SN: 23318-UP
1шт.
16
DK152300-5920
BOLT,JOINT
SN: 23318-UP
1шт.
17
DK029731-4680
BOLT,JOINT
SN: 23318-UP
1шт.
18
DK152350-6720
PIPE
SN: 23318-UP
1шт.
|1
6202-72-1211
INJECTION PUMP ASS'Y
SN: .-UP
1шт.
|1
0
INJECTION PUMP ASS'Y
SN: 23318-.
1шт.
|$$3
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.
-1шт.
|$$4
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK105220-5360
FEED PUMP ASS'Y
SN: 23318-.
1шт.
1
DK152003-1020
HOUSING
SN: 23318-UP
1шт.
2
DK152100-1120
PISTON
SN: 23318-UP
1шт.
4
DK152105-1600
PLUG
SN: .-UP
1шт.
|4
DK152105-0200
PLUG
SN: 23318-.
1шт.
5
DK029332-6030
GASKET
SN: 23318-UP
1шт.
6
DK152111-2820
TAPPET ASS'Y
SN: 23318-UP
1шт.
7
DK152112-0100
ROLLER
SN: 23318-UP
1шт.
8
DK152113-0700
PIN
SN: 23318-UP
1шт.
9
DK152114-0400
GUIDE
SN: 23318-UP
2шт.
10
DK152115-0500
VALVE
SN: 23318-UP
2шт.
12
DK152118-0900
ADAPTER
SN: 23318-UP
1шт.
14
DK152121-0200
RING,SNAP
SN: 23318-UP
1шт.
16
DK152300-5920
BOLT,JOINT
SN: 23318-UP
1шт.
17
DK029731-4680
BOLT,JOINT
SN: 23318-UP
1шт.
18
DK152350-6720
PIPE
SN: 23318-UP
1шт.
Выбрано товаров: 54
