Артикул
Название
Примечание
Количество
|$0
6202-72-1231
INJECTION PUMP ASS'Y
SN: .-UP
1шт.
|$1
0
INJECTION PUMP ASS'Y
SN: 23318-.
1шт.
|$$3
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0453 TO 0482.
-1шт.
|$$4
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$4
DK105400-7010
GOVERNOR ASS'Y
SN: .-UP
1шт.
|$5
DK105400-4661
GOVERNOR ASS'Y
SN: 23318-.
1шт.
|$$7
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0463 AND 0464.
-1шт.
2
DK154500-2020
COVER
SN: 23318-UP
1шт.
3
DK154031-3000
SCREW
SN: 23318-UP
1шт.
4
DK139206-0600
NUT
SN: .-UP
1шт.
4
DK029240-6010
NUT
SN: 23318-.
1шт.
5
DK154036-0300
PLUG
SN: 23318-UP
2шт.
6
DK020106-5040
BOLT
SN: 23318-UP
2шт.
7
DK154010-0300
SCREW
SN: 23318-UP
1шт.
8
DK020106-3840
BOLT
SN: 23318-UP
4шт.
9
DK154063-5100
COVER
SN: 23318-UP
1шт.
10
DK029020-6260
BOLT
SN: 23318-UP
2шт.
11
DK020006-2040
BOLT
SN: 23318-UP
1шт.
12
DK020006-1640
BOLT
SN: 23318-UP
1шт.
13
DK154150-6400
SPRING,GOVERNOR
SN: 23318-UP
1шт.
15
DK154011-1700
NUT
SN: 23318-UP
1шт.
18
DK154200-0220
LEVER ASS'Y,SWIVEL
SN: 23318-.
1шт.
19
DK154204-1900
BUSHING
SN: 23318-.
1шт.
21
DK016010-1640
RING,SNAP
SN: 23318-UP
2шт.
25
DK154204-1900
BUSHING
SN: 23318-.
1шт.
26
DK029141-7010
PLUG
SN: 23318-.
1шт.
30
DK154237-0100
PIN
SN: 23318-UP
1шт.
31
DK154342-2320
LEVER
SN: 23318-UP
1шт.
36
DK154358-7200
BRACKET
SN: 23318-UP
1шт.
|$0
6202-72-1231
INJECTION PUMP ASS'Y
SN: .-UP
1шт.
|$1
0
INJECTION PUMP ASS'Y
SN: 23318-.
1шт.
|$$3
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0453 TO 0482.
-1шт.
|$$4
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$4
DK105400-7010
GOVERNOR ASS'Y
SN: .-UP
1шт.
|$5
DK105400-4661
GOVERNOR ASS'Y
SN: 23318-.
1шт.
|$$7
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0463 AND 0464.
-1шт.
2
DK154500-2020
COVER
SN: 23318-UP
1шт.
3
DK154031-3000
SCREW
SN: 23318-UP
1шт.
4
DK139206-0600
NUT
SN: .-UP
1шт.
4
DK029240-6010
NUT
SN: 23318-.
1шт.
5
DK154036-0300
PLUG
SN: 23318-UP
2шт.
6
DK020106-5040
BOLT
SN: 23318-UP
2шт.
7
DK154010-0300
SCREW
SN: 23318-UP
1шт.
8
DK020106-3840
BOLT
SN: 23318-UP
4шт.
9
DK154063-5100
COVER
SN: 23318-UP
1шт.
10
DK029020-6260
BOLT
SN: 23318-UP
2шт.
11
DK020006-2040
BOLT
SN: 23318-UP
1шт.
12
DK020006-1640
BOLT
SN: 23318-UP
1шт.
13
DK154150-6400
SPRING,GOVERNOR
SN: 23318-UP
1шт.
15
DK154011-1700
NUT
SN: 23318-UP
1шт.
18
DK154200-0220
LEVER ASS'Y,SWIVEL
SN: 23318-.
1шт.
19
DK154204-1900
BUSHING
SN: 23318-.
1шт.
21
DK016010-1640
RING,SNAP
SN: 23318-UP
2шт.
25
DK154204-1900
BUSHING
SN: 23318-.
1шт.
26
DK029141-7010
PLUG
SN: 23318-.
1шт.
30
DK154237-0100
PIN
SN: 23318-UP
1шт.
31
DK154342-2320
LEVER
SN: 23318-UP
1шт.
36
DK154358-7200
BRACKET
SN: 23318-UP
1шт.
Выбрано товаров: 94
