Запчасти Komatsu 4D94LE-2Z-AD ГОЛОВКА ЦИЛИНДРОВ(№-) ДВИГАТЕЛЬ

1

YM129900-01200

BOLT

SN: 01214-UP

18шт.

2

YM129906-01340

GASKET (KIT)

SN: 01214-UP

1шт.

3

YM123907-11550

CAP

SN: 01214-UP

8шт.

4

YM129907-11700

CYLINDER HEAD ASS'Y

SN: 01214-UP

1шт.

5

YM129907-11800

GUIDE,VALVE

SN: 01214-UP

16шт.

6

YM123907-11820

GUIDE

SN: 01214-UP

8шт.

7

YM23876-020000

PLUG

SN: 01214-UP

1шт.

8

YM23876-030000

PLUG

SN: 01214-UP

4шт.

9

YM27241-400000

PLUG

SN: 01214-UP

1шт.

10

YM129907-11100

VALVE,INTAKE

SN: 01214-UP

8шт.

11

YM129907-11110

VALVE,EXHAUST

SN: 01214-UP

8шт.

12

YM129907-11120

SPRING

SN: 01214-UP

16шт.

13

YM119620-11180

SEAT

SN: 01214-UP

16шт.

14

YM124160-11340

SEAT,INTAKE (KIT)

SN: 01214-UP

8шт.

15

YM124950-11340

SEAT,EXHAUST (KIT)

SN: 01214-UP

8шт.

16

YM129907-11510

VALVE ASS'Y

SN: 01214-UP

8шт.

17

YM129150-11750

NUT

SN: 01214-UP

8шт.

18

YM123907-11830

SCREW

SN: 01214-UP

8шт.

19

YM27310-070001

COTTER

SN: 01214-UP

16шт.

20

YM119625-11880

SEAT (KIT)

SN: 01214-UP

4шт.

21

YM24311-000120

O-RING (KIT)

SN: 01214-UP

4шт.

22

YM119802-11870

PROTECTOR (KIT)

SN: 01214-UP

4шт.

1

YM129900-01200

BOLT

SN: 01214-UP

18шт.

2

YM129906-01340

GASKET (KIT)

SN: 01214-UP

1шт.

3

YM123907-11550

CAP

SN: 01214-UP

8шт.

4

YM129907-11700

CYLINDER HEAD ASS'Y

SN: 01214-UP

1шт.

5

YM129907-11800

GUIDE,VALVE

SN: 01214-UP

16шт.

6

YM123907-11820

GUIDE

SN: 01214-UP

8шт.

7

YM23876-020000

PLUG

SN: 01214-UP

1шт.

8

YM23876-030000

PLUG

SN: 01214-UP

4шт.

9

YM27241-400000

PLUG

SN: 01214-UP

1шт.

10

YM129907-11100

VALVE,INTAKE

SN: 01214-UP

8шт.

11

YM129907-11110

VALVE,EXHAUST

SN: 01214-UP

8шт.

12

YM129907-11120

SPRING

SN: 01214-UP

16шт.

13

YM119620-11180

SEAT

SN: 01214-UP

16шт.

14

YM124160-11340

SEAT,INTAKE (KIT)

SN: 01214-UP

8шт.

15

YM124950-11340

SEAT,EXHAUST (KIT)

SN: 01214-UP

8шт.

16

YM129907-11510

VALVE ASS'Y

SN: 01214-UP

8шт.

17

YM129150-11750

NUT

SN: 01214-UP

8шт.

18

YM123907-11830

SCREW

SN: 01214-UP

8шт.

19

YM27310-070001

COTTER

SN: 01214-UP

16шт.

20

YM119625-11880

SEAT (KIT)

SN: 01214-UP

4шт.

21

YM24311-000120

O-RING (KIT)

SN: 01214-UP

4шт.

22

YM119802-11870

PROTECTOR (KIT)

SN: 01214-UP

4шт.
