Запчасти Komatsu D21A-7-M ТРАНСМИССИЯ (F-R) (2 КОЖУХ) СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$$1

SERIAL NO. 80199 INDICATES D21A-7. THE OTHER MACHINES ARE AS FOLLOWS.

-1шт.

|$$2

D20A-7 = 80089

-1шт.

|$$3

D20A-7B = 80060

-1шт.

|$$4

D21A-7B = 80143

-1шт.

|1

104-15-32032

TRANSMISSION ASS'Y

SN: 78604-80198

1шт.

|$$6

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A2 TO F2320-63A2.

-1шт.

|1

104-15-32090

TRANSMISSION ASS'Y

SN: 78604-UP

1шт.

|$$8

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO 59A0¤ 60A3¤ AND 61A2 TO 63A2.

-1шт.

|1

104-15-41010

TRANSMISSION ASS'Y

SN: 80199-UP

1шт.

|$$10

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A2 TO F2320-63A2.

-1шт.

|1

104-15-00550

HOUSING ASS'Y,2ND

SN: 78604-UP

1шт.

1

0

HOUSING

SN: 78604-UP

1шт.

2

113-15-25490

PLUG

SN: 78604-UP

1шт.

3

113-15-29250

RING,SEAL (K1)

SN: 78604-UP

1шт.

4

113-15-22771

PISTON,2ND

SN: 78604-UP

1шт.

5

113-15-29261

RING,SEAL (K1)

SN: 78604-UP

1шт.

6

103-15-31250

BOLT

SN: 78604-UP

4шт.

7

362-15-11270

PIN

SN: 78604-UP

5шт.

8

104-15-32310

CARRIER

SN: 78604-UP

1шт.

9

104-15-32420

GEAR

SN: 78604-UP

3шт.

10

104-15-32560

WASHER

SN: 78604-UP

6шт.

11

104-15-39420

BEARING,NEEDLE

SN: 78604-UP

3шт.

12

104-15-32510

SHAFT

SN: 78604-UP

3шт.

13

113-15-29560

PIN,SPRING

SN: 78604-UP

3шт.

14

104-15-32270

HUB

SN: 78604-UP

1шт.
