Артикул
Название
Примечание
Количество
|$$1
SERIAL NO. 80199 INDICATES D21A-7. THE OTHER MACHINES ARE AS FOLLOWS.
-1шт.
|$$2
D20A-7 = 80089
-1шт.
|$$3
D20A-7B = 80060
-1шт.
|$$4
D21A-7B = 80143
-1шт.
|1
103-15-00612
TRANSMISSION ASS'Y
SN: 78604-80198
1шт.
|$$6
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO F2320-63A0.
-1шт.
|1
103-15-00910
TRANSMISSION ASS'Y
SN: 78604-UP
1шт.
|$$8
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO 56A0¤ 57A1¤ 58A0¤ 59A0¤ 60A1 AND 61A0¤ 62A1¤ 63A0.
-1шт.
|1
103-15-41010
TRANSMISSION ASS'Y
SN: 80199-UP
1шт.
|$$10
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO 59A0¤ 60A4¤ 61A0¤ AND 62A4¤ 63A0.
-1шт.
1
103-15-32310
CARRIER
SN: 78604-UP
1шт.
2
362-15-12510
SHAFT
SN: 78604-UP
3шт.
3
103-15-32411
GEAR
SN: 78604-UP
3шт.
4
362-15-19410
BEARING
SN: 78604-UP
3шт.
5
113-15-32560
WASHER
SN: 78604-UP
6шт.
6
04025-00312
PIN
SN: 78604-UP
3шт.
8
362-15-12620
GEAR¤ 80 TEETH,RING
SN: 78604-UP
1шт.
9
362-15-12610
GEAR¤ 74 TEETH,RING
SN: 78604-UP
1шт.
11
103-15-32221
GEAR
SN: 78604-UP
1шт.
Выбрано товаров: 20
