Артикул
Название
Примечание
Количество
|$$1
SERIAL NO. 80199 INDICATES D21A-7. THE OTHER MACHINES ARE AS FOLLOWS.
-1шт.
|$$2
D20A-7 = 80089
-1шт.
|$$3
D20A-7B = 80060
-1шт.
|$$4
D21A-7B = 80143
-1шт.
|1
103-15-41010
TRANSMISSION ASS'Y
SN: 80199-UP
1шт.
|$$6
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO 59A0¤ 60A4¤ 61A0¤ AND 62A4¤ 63A0.
-1шт.
|1
103-15-00612
TRANSMISSION ASS'Y
SN: 78604-80198
1шт.
|$$8
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO F2320-63A0.
-1шт.
|1
103-15-00910
TRANSMISSION ASS'Y
SN: 78604-UP
1шт.
|$$10
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO 56A0¤ 57A1¤ 58A0¤ 59A0¤ 60A1 AND 61A0¤ 62A1¤ 63A0.
-1шт.
|1
103-15-00730
PUMP ASS'Y
SN: 78604-UP
1шт.
1
113-15-24810
HOUSING
SN: 78604-UP
1шт.
2
103-15-34820
CASE
SN: 78604-UP
1шт.
3
103-15-34830
BRACKET
SN: 78604-UP
1шт.
4
103-15-34840
GEAR
SN: 78604-UP
1шт.
5
363-15-14880
GEAR
SN: 78604-UP
1шт.
6
113-15-29420
BEARING,NEEDLE
SN: 78604-UP
2шт.
7
113-15-29460
BEARING,NEEDLE
SN: 78604-UP
2шт.
8
113-15-24870
BOLT
SN: 78604-UP
1шт.
11
113-15-24880
PIN,DOWEL
SN: 78604-UP
1шт.
14
113-15-24860
GASKET (K1)
SN: 78604-UP
1шт.
15
01010-80855
BOLT
SN: 78604-UP
7шт.
Выбрано товаров: 27
