Запчасти Komatsu D20P-7A МАРКИРОВКА (АНГЛ.)(№78-8) МАРКИРОВКА

|$$1

SERIAL NO. 80228 INDICATES D20P-7A. THE OTHER MACHINES ARE AS FOLLOWS.

-1шт.

|$$2

D20P-7B = 80029

-1шт.

|$$3

D21P-7A = 80266

-1шт.

|$$4

D21P-7B = 80176

-1шт.

1

09690-C0355

PLATE, MARK,KOMATSU

SN: 78797-81600

1шт.

1

09690-C0224

PLATE, MARK,KOMATSU

SN: 78604-78796

1шт.

2

10F-98-21971

PLATE, MARK,D20P

SN: 78604-81600

2шт.

3

114-98-51130

PLATE, OPERATING,DOZER LEVER

SN: 80228-@

1шт.

3

114-54-48611

PLATE, OPERATING,DOZER LEVER

SN: 78604-80227

1шт.

4

114-98-44250

PLATE, OPERATING,WORK EQUIPMENT, LEVER LOCK

SN: 78604-@

2шт.

5

101-14-11191

PLATE, OPERATING,DILECT TRANSMISSION

SN: 78604-@

1шт.

6

104-98-32325

OIL CHART

SN: 81470-@

1шт.

6

104-98-32324

CHART, OIL

SN: 79172-81469

1шт.

6

104-98-32323

CHART, OIL

SN: 78604-79171

1шт.

7

09601-00835

PLATE, NAME,(LIMITED SUPPLY)

SN: 78604-@

1шт.

8

04418-13060

SCREW

SN: 78604-@

4шт.

9

104-98-44421

PLATE,KOMATSU, L.H.

SN: 81294-81600

1шт.

9

104-98-44420

PLATE, MARK,KOMATSU, L.H.

SN: 78604-81293

1шт.

9

104-98-44431

PLATE,KOMATSU, R.H.

SN: 81294-81600

1шт.

9

104-98-44430

PLATE, MARK,KOMATSU, R.H.

SN: 78604-81293

1шт.

10

114-98-44170

PLATE, OPERATING,STEERING LEVER

SN: 78604-@

1шт.

11

09667-A0481

PLATE, SAFETY,KEEP AWAY FAN AND BELT

SN: 80847-@

1шт.

11

09667-03000

PLATE, SAFETY,ENGINE COVER

SN: 78604-80846

1шт.

12

09173-03000

PLATE, SAFETY,CARRYING OUT MAINTENANCE

SN: 78604-@

1шт.

13

09651-A0641

PLATE, SAFETY,READ MANUAL BEFORE OPERATING

SN: 80847-@

1шт.

13

09651-03000

PLATE, SAFETY,BEFORE OPERATING

SN: 78604-80846

1шт.

14

09657-03003

PLATE, SAFETY,TRACK ADJUSTING

SN: 80847-@

1шт.

14

09657-03010

PLATE, SAFETY,TRACK ADJUSTING

SN: 78604-80846

1шт.

15

09653-A0481

PLATE, SAFETY,HOT OIL HAZARD, HYD. TANK CAP

SN: 80847-@

1шт.

15

09668-03000

PLATE, SAFETY,RADIATOR

SN: 78604-80846

1шт.

16

09652-30101

PLATE, CAUTION,FUEL TANK

SN: 78604-@

1шт.

17

09653-A0481

PLATE, SAFETY,HOT OIL HAZARD, HYD. TANK CAP

SN: 80847-@

1шт.

17

09653-03000

PLATE, SAFETY,HYDRAULIC TANK

SN: 78604-80846

1шт.

18

09650-30103

PLATE, INSTRUCTION,RADIATOR

SN: 78604-@

1шт.

19

09637-30161

PLATE, INSTRUCTION,AIR CLEANER

SN: 78604-@

1шт.

20

09683-30060

PLATE, OPERATING,STEERING SWITCH

SN: 78604-81600

1шт.

21

103-98-21351

PLATE, CAUTION,HYDRAULIC FILTER

SN: 78604-@

1шт.

22

09654-B0641

PLATE, SAFETY,BEFORE LEAVING OPERATOR'S SEAT

SN: 80847-@

1шт.

22

114-98-44510

PLATE, SAFETY,STEERING AND AFTER OPERATING

SN: 78604-80846

1шт.

23

104-98-41320

PLATE

SN: 79172-@

1шт.

24

09802-B0750

PLATE, SAFETY,BEFORE MOVING IN REVERSE

SN: 80847-@

1шт.

25

09806-B1201

PLATE, SAFETY,APPROACH CAUTION

SN: 80847-@

2шт.

26

09808-A0881

PLATE, SAFETY,ELECTRIC SHOCK FROM CABLE

SN: 80847-@

1шт.

27

09963-A1640

TAG,DO NOT OPERATE

SN: 80847-@

1шт.
