Запчасти Komatsu 4D95S-W-1F-T СТАРТЕР (.8KW) ЭЛЕКТРИКА

|1

600-813-4240

STARTING MOTOR ASS'Y,(2.8KW)

SN: 23318-UP

1шт.

|$$2

THE NIKKO DENKI PART NUMBER IS THAT KD IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

1

KD7-23320-0030

SHIFT LEVER ASS'Y

SN: 23318-UP

1шт.

2

KD0-47100-3590

MAGNETIC SWITCH A.

SN: 23318-UP

1шт.

3

KD0-25000-6971

SWITCH ASS'Y

SN: 23318-UP

1шт.

4

KD1-0240-06355

BOLT

SN: 23318-UP

2шт.

5

KD0-23200-0240

YOKE ASS'Y

SN: 23318-UP

1шт.

6

KD0-23785-0210

LEAD WIRE ASS'Y

SN: 23318-UP

1шт.

7

KD7-23780-0250

TERMINAL ASS'Y

SN: 23318-UP

1шт.

8

KD1-23230-0220

FIELD COIL ASS'Y

SN: 23318-UP

1шт.

9

KD1-23740-0150

BRUSH ASS'Y

SN: 23318-UP

2шт.

10

KD1-23310-0551

FRONT BRACKET ASS'Y

SN: 23318-UP

1шт.

11

KD7-23351-0160

METAL

SN: 23318-UP

1шт.

12

KD1-09066-0050

RING,CLIP

SN: 23318-UP

1шт.

13

KD1-23181-0050

STOPPER,PINION

SN: 23318-UP

1шт.

14

KD0-23500-0350

CLUTCH ASS'Y

SN: 23318-UP

1шт.

15

KD0-23600-0170

CENTER BRACKET A.

SN: 23318-UP

1шт.

16

KD7-23351-0150

METAL

SN: 23318-UP

1шт.

17

KD1-23111-0370

SHAFT ASS'Y

SN: 23318-UP

1шт.

18

KD1-23611-0461

BRACKET,CENTER

SN: 23318-UP

1шт.

19

KD7-23100-0250

ARMATURE ASS'Y

SN: 23318-UP

1шт.

20

KD1-0454-60037

BEARING,BALL

SN: 23318-UP

1шт.

21

KD1-0454-06087

BEARING,BALL

SN: 23318-UP

1шт.

|22

KD7-23700-0561

REAR BRACKET ASS'Y

SN: 23318-UP

1шт.

22

KD0-23913-0081

SPRING,BRUSH

SN: 23318-UP

4шт.

23

KD0-23750-0161

BRUSH HOLDER A.

SN: 23318-UP

1шт.

24

KD1-23740-0140

BRUSH ASS'Y

SN: 23318-UP

2шт.

25

KD1-23711-0180

BRACKET,REAR

SN: 23318-UP

1шт.

26

KD1-23901-0080

BOLT

SN: 23318-UP

2шт.

27

KD7-23920-0110

WASHER ASS'Y,(NOT SHOWN)

SN: 23318-UP

1шт.

28

KD7-09210-1400

SEAL ASS'Y,(NOT SHOWN)

SN: 23318-UP

1шт.

|1

600-813-4240

STARTING MOTOR ASS'Y,(2.8KW)

SN: 23318-UP

1шт.

|$$2

THE NIKKO DENKI PART NUMBER IS THAT KD IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

1

KD7-23320-0030

SHIFT LEVER ASS'Y

SN: 23318-UP

1шт.

2

KD0-47100-3590

MAGNETIC SWITCH A.

SN: 23318-UP

1шт.

3

KD0-25000-6971

SWITCH ASS'Y

SN: 23318-UP

1шт.

4

KD1-0240-06355

BOLT

SN: 23318-UP

2шт.

5

KD0-23200-0240

YOKE ASS'Y

SN: 23318-UP

1шт.

6

KD0-23785-0210

LEAD WIRE ASS'Y

SN: 23318-UP

1шт.

7

KD7-23780-0250

TERMINAL ASS'Y

SN: 23318-UP

1шт.

8

KD1-23230-0220

FIELD COIL ASS'Y

SN: 23318-UP

1шт.

9

KD1-23740-0150

BRUSH ASS'Y

SN: 23318-UP

2шт.

10

KD1-23310-0551

FRONT BRACKET ASS'Y

SN: 23318-UP

1шт.

11

KD7-23351-0160

METAL

SN: 23318-UP

1шт.

12

KD1-09066-0050

RING,CLIP

SN: 23318-UP

1шт.

13

KD1-23181-0050

STOPPER,PINION

SN: 23318-UP

1шт.

14

KD0-23500-0350

CLUTCH ASS'Y

SN: 23318-UP

1шт.

15

KD0-23600-0170

CENTER BRACKET A.

SN: 23318-UP

1шт.

16

KD7-23351-0150

METAL

SN: 23318-UP

1шт.

17

KD1-23111-0370

SHAFT ASS'Y

SN: 23318-UP

1шт.

18

KD1-23611-0461

BRACKET,CENTER

SN: 23318-UP

1шт.

19

KD7-23100-0250

ARMATURE ASS'Y

SN: 23318-UP

1шт.

20

KD1-0454-60037

BEARING,BALL

SN: 23318-UP

1шт.

21

KD1-0454-06087

BEARING,BALL

SN: 23318-UP

1шт.

|22

KD7-23700-0561

REAR BRACKET ASS'Y

SN: 23318-UP

1шт.

22

KD0-23913-0081

SPRING,BRUSH

SN: 23318-UP

4шт.

23

KD0-23750-0161

BRUSH HOLDER A.

SN: 23318-UP

1шт.

24

KD1-23740-0140

BRUSH ASS'Y

SN: 23318-UP

2шт.

25

KD1-23711-0180

BRACKET,REAR

SN: 23318-UP

1шт.

26

KD1-23901-0080

BOLT

SN: 23318-UP

2шт.

27

KD7-23920-0110

WASHER ASS'Y,(NOT SHOWN)

SN: 23318-UP

1шт.

28

KD7-09210-1400

SEAL ASS'Y,(NOT SHOWN)

SN: 23318-UP

1шт.
