Запчасти Komatsu 4D95S-W-1F-T ТОПЛ. НАСОС (РЕГУЛЯТОР) (/) ТОПЛИВН. СИСТЕМА

|$0

6202-72-1231

INJECTION PUMP ASS'Y

SN: .-UP

1шт.

|$1

0

INJECTION PUMP ASS'Y

SN: 23318-.

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0453 TO 0482.

-1шт.

|$$4

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$4

DK105400-7010

GOVERNOR ASS'Y

SN: .-UP

1шт.

|$5

DK105400-4661

GOVERNOR ASS'Y

SN: 23318-.

1шт.

|$$7

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0463 AND 0464.

-1шт.

1

DK154000-6300

HOUSING

SN: 23318-UP

1шт.

2

DK029632-5070

O-RING

SN: 23318-UP

1шт.

3

DK154007-2900

PLUG

SN: 23318-UP

1шт.

4

DK154007-0200

ADAPTER

SN: 23318-UP

1шт.

5

DK020018-1840

BOLT

SN: 23318-UP

1шт.

6

DK154350-1900

PLATE

SN: 23318-UP

1шт.

7

DK020006-1440

BOLT

SN: 23318-UP

6шт.

8

DK154010-0100

SCREW

SN: 23318-UP

1шт.

9

DK154011-0100

NUT,LOCK

SN: 23318-UP

1шт.

10

DK154050-1720

LIMITER

SN: .-UP

1шт.

10

DK155404-5300

CAP

SN: 23318-.

1шт.

11

DK154100-9720

FLYWEIGHT ASS'Y

SN: 23318-UP

1шт.

12

DK029321-2020

WASHER,SPRING

SN: 23318-UP

1шт.

13

DK029231-2030

NUT

SN: 23318-UP

1шт.

14

DK154123-0120

SLEEVE

SN: 23318-UP

1шт.

15

DK029801-0030

BEARING

SN: 23318-UP

1шт.

16

DK029311-0010

SHIM, 0.20MM

SN: 23318-UP

-2шт.

16

DK029311-0180

SHIM, 0.30MM

SN: 23318-UP

-2шт.

16

DK029311-0190

SHIM, 0.40MM

SN: 23318-UP

-2шт.

16

DK139410-0000

SHIM, 0.50MM

SN: 23318-UP

-2шт.

16

DK029311-0210

SHIM, 1.00MM

SN: 23318-UP

-2шт.

16

DK139410-0100

SHIM, 1.50MM

SN: 23318-UP

-2шт.

16

DK139410-3000

SHIM, 2.00MM

SN: .-UP

-2шт.

16

DK139410-3100

SHIM, 3.00MM

SN: .-UP

-2шт.

16

DK139410-3200

SHIM, 4.00MM

SN: .-UP

-2шт.

17

DK154154-1200

SPRING

SN: 23318-UP

1шт.

18

DK154185-4520

CAPSULE,SPRING

SN: 23318-UP

1шт.

19

DK029201-6080

NUT

SN: 23318-UP

1шт.

20

DK154210-0920

GUIDE LEVER ASS'Y

SN: 23318-UP

1шт.

21

DK154230-3920

LINK

SN: 23318-UP

1шт.

22

DK016010-0540

RING,SNAP

SN: 23318-UP

1шт.

23

DK154236-4100

LEVER,TENSION

SN: 23318-UP

1шт.

24

DK154350-7700

GASKET

SN: 23318-UP

1шт.

25

DK154179-0720

CAPSULE,SPRING

SN: 23318-UP

1шт.

26

DK029201-6010

NUT

SN: 23318-UP

1шт.
