Запчасти Komatsu D20AG-7 МАРКИРОВКА (ЯПОН.)(№788-78) МАРКИРОВКА¤ ИНСТРУМЕНТ И РЕМКОМПЛЕКТЫ

|1

134-98-11210

PLATE KIT

SN: 78086-UP

1шт.

1

0

PLATE¤ SAFETY,HYDRAULIC TANK

SN: 78086-UP

1шт.

2

0

PLATE¤ SAFETY,RADIATOR

SN: 78086-UP

1шт.

3

0

PLATE¤ CAUTION,BEFORE AND AFTER OPERATION

SN: 78086-UP

1шт.

4

0

PLATE¤ SAFETY,BEFORE OPERATING

SN: 78086-UP

1шт.

5

0

PLATE¤ CAUTION,SAFETY COMFIRM OF REAR

SN: 78086-UP

1шт.

6

14X-98-11161

PLATE¤ SAFETY,ADJUSTING TRACK SHOE

SN: 78086-UP

1шт.

7

09652-01101

PLATE¤ CAUTION,FUEL TANK

SN: 78086-UP

1шт.

8

09637-01163

PLATE¤ INSTRUCTION,AIR CLEANER

SN: 78086-UP

1шт.

9

103-98-21251

PLATE¤ INSTRUCTION,HYDRAULIC TANK¤ FILTER

SN: 78086-UP

1шт.

10

101-98-51952

PLATE¤ DATA

SN: 78604-UP

1шт.

|10

101-98-51951

PLATE¤ DATA

SN: 76527-78603

1шт.

11

101-98-51971

PLATE¤ MARK,D20A

SN: 75001-UP

2шт.

12

104-98-44420

PLATE¤ MARK,KOMATSU¤ L.H.

SN: 75001-UP

1шт.

|12

104-98-44430

PLATE¤ MARK,KOMATSU¤ R.H.

SN: 75001-UP

1шт.

13

09690-C0224

PLATE¤ MARK,KOMATSU

SN: 75001-UP

1шт.

14

09601-00835

PLATE¤ NAME,(LIMITED SUPPLY)

SN: 75001-UP

1шт.

|14

04418-13060

SCREW

SN: 75001-UP

4шт.

15

104-98-32133

CHART¤ OIL

SN: 78604-UP

1шт.

|15

104-98-32132

CHART¤ OIL

SN: 76527-78603

1шт.

16

114-98-44250

PLATE¤ OPERATING,PARKING BRAKE¤ LEVER LOCK

SN: 75001-UP

1шт.

17

114-98-44250

PLATE¤ OPERATING,WORK EQUIPMENT¤ LEVER LOCK

SN: 75001-UP

1шт.

18

114-54-48611

PLATE¤ OPERATING,DOZER LEVER

SN: 75001-UP

1шт.

19

114-98-44170

PLATE¤ OPERATING,STEERING LEVER

SN: 75001-UP

1шт.

20

101-14-11191

PLATE¤ OPERATING,TRANSMISSION LEVER

SN: 75001-UP

1шт.

21

21X-98-21190

TAG¤ CAUTION,DO NOT OPERATE

SN: 78086-UP

1шт.
