Запчасти Komatsu 4D94LE-2Z-AB СТАРТЕР (.KW) (ВНУТР. ЧАСТИ)(№-) ДВИГАТЕЛЬ

1

YM129910-77022

STARTING MOTOR ASS'Y,(2.3KW)

SN: 01214-UP

1шт.

2

YM129900-77400

ARMATURE ASS'Y

SN: 01214-UP

1шт.

3

YMX2114155110

BALL

SN: 01214-UP

1шт.

4

YMX2114255110

BEARING

SN: 01214-UP

1шт.

5

YM129900-77440

FIELD COIL ASS'Y

SN: 01214-UP

1шт.

6

YM129900-77450

BRUSH (+)

SN: 01214-UP

2шт.

7

YM171008-77450

SCREW

SN: 01214-UP

4шт.

8

YM129900-77460

COVER,REAR

SN: 01214-UP

1шт.

9

YM129900-77480

BRUSH HOLDER ASS'Y

SN: 01214-UP

1шт.

10

YM129900-77500

BRUSH (-)

SN: 01214-UP

2шт.

11

YMX2130631300

BRUSH

SN: 01214-UP

4шт.

|12

YM129910-77752

GEAR CASE ASS'Y

SN: 01214-UP

1шт.

|12

YM129910-77532

PINION CLUTCH ASS'Y

SN: 01214-UP

1шт.

12

YM129910-77520

CLUTCH ASS'Y

SN: 01214-UP

1шт.

13

YM171008-77730

BEARING

SN: 01214-UP

1шт.

14

YM171008-77740

BEARING

SN: 01214-UP

1шт.

15

YM129910-77541

O-RING

SN: 01214-UP

1шт.

16

YM129910-77550

SHAFT,PINION

SN: 01214-UP

1шт.

17

YM129900-77550

STOPPER SET

SN: 01214-UP

1шт.

18

YM129900-77710

CASE,GEAR

SN: 01214-UP

1шт.

19

YM24326-000850

O-RING

SN: 01214-UP

1шт.

20

YM129900-77602

RETAINER

SN: 01214-UP

1шт.

21

YM129900-77721

O-RING

SN: 01214-UP

1шт.

22

YM129900-77591

MAGNETIC SWITCH A.

SN: 01214-UP

1шт.

23

YM129900-77620

SHIFT LEVER ASS'Y

SN: 01214-UP

1шт.

24

YM129900-77640

BOLT,THROUGH

SN: 01214-UP

2шт.

25

YM129900-77650

DUST COVER ASS'Y

SN: 01214-UP

1шт.

26

YM171008-77750

COVER,TERMINAL

SN: 01214-UP

1шт.
