Запчасти Komatsu SAA6D140E-6B ПОРШЕНЬ И ШАТУН (№7-) ПОРШЕНЬ И ШАТУН

1

6262-31-2110

Piston

SN: 730004-UP

3шт.

2

6211-31-2410

Pin

SN: 730004-UP

6шт.

3

04065-05220

Ring, Snap

SN: 730004-UP

12шт.

3

6262-31-2010

Ring Assembly

SN: 730004-UP

6шт.

4

Ring

SN: 730004-UP

1шт.

5

Ring

SN: 730004-UP

1шт.

6

Ring

SN: 730004-UP

1шт.

6

6261-31-3100

Connecting Rod Assembly

SN: 730004-UP

6шт.

7

Rod

SN: 730004-UP

1шт.

8

Cap

SN: 730004-UP

1шт.

9

6261-31-3130

Bushing

SN: 730004-UP

1шт.

10

6210-31-3310

Bolt

SN: 730004-UP

2шт.

11

02400-10413

Pin, Dowel

SN: 730004-UP

2шт.

|$13

6210-32-3040

Metal Assembly, Standard

SN: 730004-UP

6шт.

|$14

6210-39-3040

Metal Assembly, Undersize 0.25mm

SN: 730004-UP

6шт.

|$15

6210-38-3040

Metal Assembly, Undersize 0.50mm

SN: 730004-UP

6шт.

|$16

6210-37-3040

Metal Assembly, Undersize 0.75mm

SN: 730004-UP

6шт.

|$17

6210-36-3040

Metal Assembly, Undersize 1.00mm

SN: 730004-UP

6шт.

12

Metal, Lower

SN: 730004-UP

1шт.

12

Metal, Lower, Undersize 0.25mm

SN: 730004-UP

1шт.

12

Metal, Lower, Undersize 0.50mm

SN: 730004-UP

1шт.

12

Metal, Lower, Undersize 0.75mm

SN: 730004-UP

1шт.

12

Metal, Lower, Undersize 1.00mm

SN: 730004-UP

1шт.

13

Metal, Upper

SN: 730004-UP

1шт.

13

Metal, Upper, Undersize 0.25mm

SN: 730004-UP

1шт.

13

Metal, Upper, Undersize 0.50mm

SN: 730004-UP

1шт.

13

Metal, Upper, Undersize 0.75mm

SN: 730004-UP

1шт.

13

Metal, Upper, Undersize 1.00mm

SN: 730004-UP

1шт.

1

6262-31-2110

Piston

SN: 730004-UP

3шт.

2

6211-31-2410

Pin

SN: 730004-UP

6шт.

3

04065-05220

Ring, Snap

SN: 730004-UP

12шт.

3

6262-31-2010

Ring Assembly

SN: 730004-UP

6шт.

4

Ring

SN: 730004-UP

1шт.

5

Ring

SN: 730004-UP

1шт.

6

Ring

SN: 730004-UP

1шт.

6

6261-31-3100

Connecting Rod Assembly

SN: 730004-UP

6шт.

7

Rod

SN: 730004-UP

1шт.

8

Cap

SN: 730004-UP

1шт.

9

6261-31-3130

Bushing

SN: 730004-UP

1шт.

10

6210-31-3310

Bolt

SN: 730004-UP

2шт.

11

02400-10413

Pin, Dowel

SN: 730004-UP

2шт.

|$13

6210-32-3040

Metal Assembly, Standard

SN: 730004-UP

6шт.

|$14

6210-39-3040

Metal Assembly, Undersize 0.25mm

SN: 730004-UP

6шт.

|$15

6210-38-3040

Metal Assembly, Undersize 0.50mm

SN: 730004-UP

6шт.

|$16

6210-37-3040

Metal Assembly, Undersize 0.75mm

SN: 730004-UP

6шт.

|$17

6210-36-3040

Metal Assembly, Undersize 1.00mm

SN: 730004-UP

6шт.

12

Metal, Lower

SN: 730004-UP

1шт.

12

Metal, Lower, Undersize 0.25mm

SN: 730004-UP

1шт.

12

Metal, Lower, Undersize 0.50mm

SN: 730004-UP

1шт.

12

Metal, Lower, Undersize 0.75mm

SN: 730004-UP

1шт.

12

Metal, Lower, Undersize 1.00mm

SN: 730004-UP

1шт.

13

Metal, Upper

SN: 730004-UP

1шт.

13

Metal, Upper, Undersize 0.25mm

SN: 730004-UP

1шт.

13

Metal, Upper, Undersize 0.50mm

SN: 730004-UP

1шт.

13

Metal, Upper, Undersize 0.75mm

SN: 730004-UP

1шт.

13

Metal, Upper, Undersize 1.00mm

SN: 730004-UP

1шт.
