Запчасти Komatsu D155A-5 ТРАНСМИССИЯ (1¤2¤ И 3 МУФТА) СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$4

17A-15-00012

TRANSMISSION ASS'Y

SN: 65255-UP

1шт.

|$5

17A-15-00011

TRANSMISSION ASS'Y

SN: 65001-65254

1шт.

|$6

17A-15-21040

TRANSMISSION ASS'Y

SN: 65725-UP

1шт.

|$$5

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO F2320-61A0.

-1шт.

|$14

17A-15-00231

HOUSING ASS'Y

SN: (51209)-UP

1шт.

|$15

17A-15-00230

HOUSING ASS'Y

SN: 65001-(51208)

1шт.

1

0

HOUSING

SN: (51209)-UP

1шт.

1

0

HOUSING

SN: 65001-(51208)

1шт.

1

17A-15-00231

HOUSING ASS'Y

SN: (51209)-UP

1шт.

1

17A-15-00230

HOUSING ASS'Y

SN: 65001-(51208)

1шт.

1

0

HOUSING

SN: 65001-UP

1шт.

2

568-15-11380

PLUG

SN: 65001-UP

1шт.

3

562-15-19230

RING (K3)

SN: 65001-UP

1шт.

4

17M-15-42730

PISTON

SN: (51427)-UP

1шт.

4

17A-15-22730

PISTON

SN: 65001-(51426)

1шт.

5

582-15-19250

RING (K3)

SN: (152834)-UP

1шт.

5

566-15-79260

RING (K3)

SN: 65001-(152833)

1шт.

6

566-15-12880

SPRING

SN: 65001-UP

12шт.

7

232-15-11270

PIN

SN: 65001-UP

6шт.

8

175-15-42880

SPRING

SN: 65001-UP

18шт.

9

04020-01434

PIN

SN: 65001-UP

2шт.

10

17A-15-22660

GEAR

SN: 65001-UP

1шт.

11

195-15-32710

DISC

SN: 65001-UP

3шт.

12

425-15-12740

PLATE

SN: 65001-UP

2шт.

|$40

17A-15-00241

HOUSING ASS'Y

SN: (51427)-UP

1шт.

|$41

17A-15-00240

HOUSING ASS'Y

SN: 65001-(51426)

1шт.

13

0

HOUSING

SN: (51427)-UP

1шт.

13

0

HOUSING

SN: 65001-(51426)

1шт.

14

145-14-11320

PLUG

SN: 65001-UP

1шт.

15

144-15-22881

RING (K3)

SN: 65001-UP

1шт.

16

17M-15-42771

PISTON

SN: (51396)-UP

1шт.

16

17A-15-22740

PISTON

SN: 65001-(51395)

1шт.

17

568-15-12830

RING (K3)

SN: 65001-UP

1шт.

18

07000-72020

O-RING (K3)

SN: 65001-UP

1шт.

19

195-15-48140

SPRING

SN: 65001-UP

12шт.

20

175-15-42880

SPRING

SN: 65001-UP

24шт.

21

04020-01434

PIN

SN: 65001-UP

2шт.

22

195-15-32710

DISC

SN: 65001-UP

4шт.

23

425-15-12740

PLATE

SN: 65001-UP

3шт.

|$56

17A-15-00250

HOUSING ASS'Y

SN: 65001-UP

1шт.

24

0

HOUSING

SN: 65001-UP

1шт.

25

145-14-11320

PLUG

SN: 65001-UP

1шт.

26

425-15-19250

RING (K3)

SN: 65001-UP

1шт.

27

17A-15-22750

PISTON

SN: 65001-UP

1шт.

28

582-15-19250

RING (K3)

SN: (152834)-UP

1шт.

28

566-15-79260

RING (K3)

SN: 65001-(152833)

1шт.

29

195-15-48140

SPRING

SN: 65001-UP

12шт.

30

175-15-42880

SPRING

SN: 65001-UP

24шт.

31

04020-01434

PIN

SN: 65001-UP

2шт.

32

17M-15-42640

GEAR

SN: (51430)-UP

1шт.

32

17A-15-22640

GEAR

SN: 65001-(51429)

1шт.

33

195-15-32710

DISC

SN: 65001-UP

4шт.

34

425-15-12740

PLATE

SN: 65001-UP

3шт.
