Запчасти Komatsu D155A-1 ЗАДН. КРЫШКА (ДЛЯ IRAQ)(№87-) ЧАСТИ КОРПУСА

1

175-54-33241

BRACKET

SN: 28750-UP

1шт.

2

01010-31440

BOLT

SN: 28750-UP

4шт.

3

01643-31445

WASHER

SN: 28750-UP

4шт.

4

175-54-36120

COVER

SN: 28750-UP

1шт.

5

01010-31250

BOLT

SN: 28750-UP

4шт.

6

01643-31232

WASHER

SN: 28750-UP

4шт.

7

01010-31235

BOLT

SN: 28750-UP

2шт.

8

01643-31232

WASHER

SN: 28750-UP

2шт.

9

175-978-2140

COVER

SN: 28750-UP

1шт.

10

01010-31235

BOLT

SN: 28750-UP

3шт.

11

01643-31232

WASHER

SN: 28750-UP

3шт.

12

175-54-33742

COVER

SN: 28750-UP

1шт.

13

195-54-16210

BOLT

SN: 28750-UP

8шт.

14

175-54-33851

COVER,(WITHOUT REAR PCU)

SN: 28750-UP

1шт.

15

01010-31225

BOLT,(WITHOUT REAR PCU)

SN: 28750-UP

4шт.

16

01643-31232

WASHER,(WITHOUT REAR PCU)

SN: 28750-UP

4шт.

17

175-54-33861

COVER,(WITHOUT REAR PCU)

SN: 28750-UP

1шт.

18

01010-31225

BOLT,(WITHOUT REAR PCU)

SN: 28750-UP

3шт.

19

01643-31232

WASHER,(WITHOUT REAR PCU)

SN: 28750-UP

3шт.

20

175-54-33871

COVER,(WITHOUT REAR PCU)

SN: 28750-UP

1шт.

21

01010-31225

BOLT,(WITHOUT REAR PCU)

SN: 28750-UP

3шт.

22

01643-31232

WASHER,(WITHOUT REAR PCU)

SN: 28750-UP

3шт.

23

175-54-33314

COVER

SN: 28750-UP

1шт.

24

09459-00000

LOCK

SN: 28750-UP

2шт.

25

175-54-37412

COVER

SN: 28750-UP

1шт.

26

175-54-37421

COVER

SN: 28750-UP

1шт.

27

120-54-12210

SPRING

SN: 28750-UP

2шт.

28

04205-00620

PIN

SN: 28750-UP

4шт.

29

01641-00608

WASHER

SN: 28750-UP

4шт.

30

04050-01610

PIN

SN: 28750-UP

4шт.

31

195-54-26210

BOLT

SN: 28750-UP

9шт.

32

175-54-38530

CAP

SN: 28750-UP

2шт.

33

175-54-38540

CAP

SN: 28750-UP

4шт.
