Запчасти John Deere 92DLC 128 - AUXILIARY FUNCTION VALVE, HOSES, CIRCUIT RELIEF VALVES AND PEDAL LOCK KIT 3360 - EXCAVATOR 33

6

12M7066

LOCK WASHER

10 MM

9шт.

7

19M7550

CAP SCREW

M10 X 35

5шт.

10

9728875

FOOTREST

(SUB FOR TH110195)

1шт.

11

19M7402

CAP SCREW

M10 X 25

2шт.

12

24M7028

WASHER

10.500 X 20 X 2 MM

2шт.

13

8046079

PEDAL

(SUB FOR TH110191) (SUB FOR AT134292)

1шт.

14

14M7273

NUT

M8

1шт.

16

34M7062

SPRING PIN

5 X 32 MM

1шт.

17

34M7124

SPRING PIN

8 X 30 MM, (SUB FOR 34M7065)

1шт.

18

4211166

SUPPORT

(SUB FOR TH110190)

1шт.

19

19M8008

CAP SCREW

M8 X 35, (SUB FOR AT134128)

1шт.

21

9074843

HYD ACTUATED CONTROL VALVE

(SUB FOR TH110188) (USE WITH (2) TH111705 CIRCUIT RELIEF VALVE)

1шт.

22

45M3667

PIN FASTENER

10 X 28 MM, (SUB FOR TH105681)

1шт.

23

9733399

BRACKET

(SUB FOR TH110192) (SUB FOR AT134303)

1шт.

24

4149125

SPRING

(SUB FOR TH106748)

1шт.

25

8034081

BRACKET

(SUB FOR TH110193)

1шт.

26

19M8761

SCREW

M10 X 22, (SUB FOR TH102993)

2шт.

27

11M7082

COTTER PIN

2.500 X 25 MM, (SUB FOR 11M7080)

1шт.

28

4211167

SPACER

(SUB FOR TH110194)

1шт.

33

9728874

PLATE

(SUB FOR TH110189)

1шт.

42

4228353

PRESSURE RELIEF VALVE

(SUB FOR TH111705) (NOT ILLUSTRATED) USE WITH TH110188 AUXILIARY FUNCTION VALVE (RELIEF SETTING AT 4270 PSI)

2шт.

52

3040042

MAT

(SUB FOR AT132472)

1шт.

54

19M7938

CAP SCREW

(SUB FOR AT132473)

1шт.

60

TH108154

KIT

(CONTAINS ALL ITEMS ON THIS PAGE - FOR ADDITIONAL COMPONENTS SEE FOLLOWING PAGE) (ALSO ORDER AT50269, R27095, AT48422 AND AU43156, THIS APPLICATION)

1шт.
