Артикул
Название
Примечание
Количество
2
4204543
FRAME
(SUB FOR TH108623)
1шт.
3
LOCK
(ORDER INDIVIDUAL COMPONENTS)
1шт.
3A
4204546
SPRING
(SUB FOR TH108625)
1шт.
3B
4204547
PIN
(SUB FOR TH108626)
1шт.
3C
4204548
LEVER
(SUB FOR TH108627)
1шт.
4
LOCK
(ORDER INDIVIDUAL COMPONENTS)
1шт.
4A
4204546
SPRING
(SUB FOR TH108625)
1шт.
4B
4204547
PIN
(SUB FOR TH108626)
1шт.
4C
4204548
LEVER
(SUB FOR TH108627)
1шт.
8
4204549
ISOLATOR
(SUB FOR TH108629)
1шт.
9
TH108630
WINDOWPANE
1шт.
10
4204551
BUSHING
(SUB FOR TH108631)
2шт.
11
21M7420
SCREW
M6 X 16
2шт.
12
4204552
STOP
(SUB FOR TH108632)
2шт.
13
21M7246
SCREW
M6 X 16
4шт.
14
12M7006
LOCK WASHER
6 MM
4шт.
16
LOCK
(ORDER INDIVIDUAL COMPONENTS)
1шт.
16A
494918
SPRING
(SUB FOR TH106783)
1шт.
16B
4204556
PIN
(SUB FOR TH108635)
1шт.
16C
4204548
LEVER
(SUB FOR TH108627)
1шт.
17
LOCK
(ORDER INDIVIDUAL COMPONENTS)
1шт.
17A
494918
SPRING
(SUB FOR TH106783)
1шт.
17B
4204556
PIN
(SUB FOR TH108635)
1шт.
17C
4204548
LEVER
(SUB FOR TH108627)
1шт.
21
4204557
BRACKET
(SUB FOR TH108637)
2шт.
22
19M7881
SCREW
M8 X 20
4шт.
23
12M7056
LOCK WASHER
8 MM, (SUB FOR 12M7065)
4шт.
25
4204559
ISOLATOR
(SUB FOR TH108639)
1шт.
26
37M7095
SCREW
4шт.
28
4204560
ISOLATOR
(SUB FOR TH108640)
1шт.
29
TH108641
WINDOWPANE
1шт.
30
4294508
BUMPER
(SUB FOR TH108642) (SUB FOR AT201032)
2шт.
32
4204564
STOP
(SUB FOR TH108644)
1шт.
33
21M7192
SCREW
M8 X 16
2шт.
34
12M7056
LOCK WASHER
8 MM, (SUB FOR 12M7065)
2шт.
35
24M7055
WASHER
8.400 X 16 X 1.600 MM
2шт.
36
4204565
ISOLATOR
(SUB FOR TH108645)
1шт.
43
4204595
SHIM
(SUB FOR TH108678)
2шт.
44
SHIM
(K) (SUB AT146245) (1.0) ( TH108679 NO LONGER AVAILABLE)
1шт.
45
SHIM
(K) (SUB AT146245) (1.2) ( TH108680 NO LONGER AVAILABLE)
1шт.
46
SHIM
(K) (SUB AT146245) (1.6) ( TH108681 NO LONGER AVAILABLE)
1шт.
47
21M7192
SCREW
M8 X 16
4шт.
48
12M7056
LOCK WASHER
8 MM, (SUB FOR 12M7065)
4шт.
49
24M7055
WASHER
8.400 X 16 X 1.600 MM
4шт.
50
CAB
(4196647J NLA) (SUB FOR AT114976) (NOT ILLUSTRATED) (CONTAINS ALL ITEMS ON THIS PAGE - ADDITIONAL COMPONENTS LISTED ON FOLLOWING PAGES)
1шт.
Выбрано товаров: 49
