Запчасти John Deere 90 6 - PROPEL MOTOR 260 - AXLES AND SUSPENSION SYSTEMS 2

1

T74522

ADAPTER FITTING

1шт.

2

T74510

PIN

1шт.

3

T74509

SPOOL

1шт.

4

24M7274

WASHER

M6 X 12 X 1.0

ARшт.

5

24M7273

SHIM

M6 X 12 X 0.2

ARшт.

6

24M7272

SHIM

M6 X 12 X 0.1

ARшт.

7

T74511

SPRING

1шт.

8

U15415

O-RING

(K) (SUB FOR T24211)

1шт.

9

T74550

O-RING

(K)

4шт.

10

22M7111

SET SCREW

M6 X 6

2шт.

11

R27218

FITTING PLUG

1шт.

12

T70177

O-RING

(K)

1шт.

13

T74521

ADAPTER FITTING

1шт.

14

15M7033

PIPE PLUG

M10 X 1

2шт.

15

T74518

FITTING

1шт.

16

19M8444

SCREW

M12 X 60

4шт.

17

T74508

COVER

1шт.

18

15M7032

PIPE PLUG

M8 X 1

2шт.

19

T74553

O-RING

(K)

2шт.

20

T74516

FLOW CONTROL HYD. VALVE

1шт.

21

T74552

O-RING

(K)

1шт.

22

T74551

BACK-UP RING

(K)

1шт.

23

T74517

FITTING

1шт.
