0
AP35992
Arm
1шт.
0B
4197842
Bushing
(SUB FOR TH110558)
2шт.
0C
4356103
Bushing
(SUB FOR P65749 OR 4374061)
4шт.
0D
4197031
Bushing
(USE WITH TH100624 AND TH100625 ) (SUB P66187 ) (SUB FOR TH110546)
1шт.
P66187
Bushing
(SUB FOR TH110546 ) (USE WI TH 19M7941 AND (2) 14M7276)
1шт.
0E
4197029
Bushing
(USE WITH TH106052 AND TH106053 ) (SUB P65093 ) (SUB FOR TH110545)
1шт.
Spacer
( P65093 NLA (SUB FOR TH110545 ) (USE WITH 19M8020 AND (2) 14M7276)
1шт.
1
TH105979
Seal
2шт.
2
4349913
Seal
(SUB FOR P65743)
4шт.
3
8066896
Link
(SUB FOR AP35994)
1шт.
3B
4445476
Bushing
(SUB FOR 4356105 ) (SUB FOR P65761)
2шт.
3C
4117954
Seal
(SUB FOR TH106006)
4шт.
3D
4349913
Seal
(SUB FOR P65743)
2шт.
3E
4356103
Bushing
(SUB FOR P65749 OR 4374061)
2шт.
3F
TH100074
Lubrication Fitting
2шт.
4
3076932J
Link
(SUB FOR P65733 OR 3076932)
1шт.
5
AP36788
Link
(SUB FOR P65766)
1шт.
7
3076942
Pin
(SUB FOR P65734)
1шт.
8
3076944
Pin
(SUB FOR P65738)
1шт.
10
3076951
Pin
(SUB FOR P65739)
1шт.
11
3076955
Pin
(SUB FOR P65763)
1шт.
12
3076954
Pin
(SUB FOR P65764)
1шт.
13
3076948
Pin
(SUB FOR P65765)
1шт.
14
4065688
Retainer
(SUB FOR TH100624)
5шт.
15
4141000
Ring
(SUB FOR TH106052)
1шт.
16
4065689
Pin Fastener
17.500 X 81 mm (0.689" X 3.189") (SUB FOR TH100625)
5шт.
17
4141001
Pin
16 X 62 mm (0.630" X 2. 441") (SUB FOR TH106053)
1шт.
20
4406388
O-Ring
(SUB FOR AT250759)
4шт.
22
T77857
O-Ring
12.421 X 1.778 mm (0.489" X 0.070")
2шт.
24
AP36006
Hydraulic Hose
2шт.
27
4374459
Plate
(SUB FOR P65704) (1.0)
6шт.
28
4374437
Plate
(SUB FOR P65703) (2.0)
1шт.
29
P65745
Plate
(1.0)
2шт.
30
P65746
Plate
(1.0)
2шт.
31
P65744
Plate
(2.0)
1шт.
41
TH100074
Lubrication Fitting
1шт.
42
TH100074
Lubrication Fitting
1шт.
43
TH100074
Lubrication Fitting
1шт.
44
19M8351
Cap Screw
M16 X 125 (SUB FOR 19M7941)
5шт.
45
19M8020
Cap Screw
M16 X 100
1шт.
46
14M7276
Nut
M16
12шт.
49
Cylinder
(BUCKET CYLINDER) (SEE S EPARATE PAGE FOR DETAIL)
1шт.
50
AT190711
Arm
WHOLE GOODS (INCLUDES ARM, BUCKET CYLI NDER, HOSES AND LINKAGE) (WHOLE GOODS)
1шт.
