Запчасти John Deere 92DLC 10 - Brake Valve 0260 HYDRAULIC SYSTEM

0

9083458

Flow Control Hyd. Valve

(SUB FOR AT205917)

1шт.

1

Housing

1шт.

4

4200879

Orifice

(SUB FOR TH109128)

1шт.

7

4185136

Spring

(SUB FOR T107783)

1шт.

8

4188556

Spool

(SUB FOR TH111230)

1шт.

9

CH11570

O-Ring

13.800 X 2.400 mm

1шт.

11

15H560

Pipe Plug

1/16"

3шт.

13

15M7036

Drain Plug

1шт.

15

R26552

Ball

7.938 mm

1шт.

16

4197136

Seat

(SUB FOR TH111285)

1шт.

17

942011

Fitting Plug

(SUB FOR 94-2011 AND TH100434)

1шт.

20

4180687

Spring

(SUB FOR T107785)

2шт.

21

4180688

Compression Spring

(SUB FOR T107786)

2шт.

22

T110441

O-Ring

34.700 X 3.500 mm

2шт.

23

4195070

Fitting Plug

(SUB FOR T107794)

2шт.

28

4174629

Poppet

(SUB FOR T107788)

2шт.

29

4174072

Spring

(SUB FOR T107789)

2шт.

30

AT318035

O-Ring

(SUB FOR 4506424, TH100055)

2шт.

31

4195071

Fitting Plug

(SUB FOR T107795)

2шт.

36

9080502

Pressure Relief Valve

(SUB FOR AT205916)

2шт.

41

M800650

Packing

2шт.

42

4208977

Drain Plug

(SUB FOR TH111351)

2шт.

44

M800650

Packing

1шт.

45

4208977

Drain Plug

(SUB FOR TH111351)

1шт.
