Запчасти John Deere 90ELC 237 - HYDRAULIC PUMP DRIVE AND MOUNTING PLATE (559603 - ) 2160 HYDRAULIC SYSTEM

1

19M8600

Cap Screw

M10 X 50

10шт.

19M7935

Cap Screw

M10 X 55 THRU MUFFLER BRACKET

2шт.

2

T160875

Plate

1шт.

3

Hub

(SUB AT180185)

1шт.

4

T108082

Insert

4шт.

5

T108085

Cap Screw

4шт.

6

T108084

Flange

1шт.

7

T108083

Disk

FLEX COUPLING

1шт.

8

22M7130

Set Screw

M16 X 20

2шт.

9

19M8341

Screw

M12 X 45 SOCKET HEAD

6шт.

10

19H3483

Cap Screw

3/8" X 1-1/8"

8шт.

11

AT180185

Drive

1шт.
