Запчасти John Deere 90B 2 - HOOD, FENDER EXTENSION, AND SWING MOTOR COVER 70 - GRILLE, HOOD, FENDERS AND BUMPER
№
Артикул
Название
Примечание
Количество
1
T33802
SHAFT KEY
(USED WITH ALL LOCKS)
1шт.
2
AU43731
LOCK
(WITHOUT KEY)
1шт.
AT38176
LOCK
(WITHOUT KEY)
1шт.
3
AU43398
COVER
(SUB AT42071)
1шт.
AT42071
COVER
(SUB FOR AT61164)
1шт.
4
AT38842
HOOD
WITH FUEL COVER
1шт.
5
T11234
LOCK NUT
4шт.
6
19H1765
CAP SCREW
3/8" X 1-3/4"
4шт.
7
14H812
NUT
3/8"
2шт.
8
12H304
LOCK WASHER
3/8"
2шт.
10
AT38844
EXTENSION
HOOD
1шт.
11
19H1648
CAP SCREW
3/8" X 3/4"
17шт.
12
24H1305
WASHER
13/32" X 13/16" X 0.065"
2шт.
13
R31618
HANDLE
1шт.
14
24H1299
WASHER
3/8" X 1-1/4" X 0.065"
14шт.
15
12H304
LOCK WASHER
3/8"
16шт.
16
AU43399
COVER
SWING MOTOR
1шт.
17
T40255
SCREW
2шт.
18
T35937
BUSHING
HOOD AIR INLET
1шт.
21
AT38845
BRACKET
HOOD EXTENSION
1шт.
22
24H1625
WASHER
17/32" X 1" X 0.120"
4шт.
23
12H301
LOCK WASHER
1/2"
4шт.
25
T25653
PIN FASTENER
HEADED
1шт.
26
T41649
STRAP
1шт.
27
24H1338
WASHER
33/64" X 7/8" X 0.048"
1шт.
28
T25922
WASHER
(USE IF AVAILABLE)
ARшт.
29
11M7083
COTTER PIN
3.200 X 50 MM
2шт.
30
T41648
STRAP
1шт.
31A
AT32404
EXTENSION
FENDER R.H. (SUB AT51099) (WITHOUT AIR CONDITIONING) (WITH SUCKER FAN)
1шт.
31B
AT51099
EXTENSION
R.H. (WITHOUT AIR CONDITIONING) (WITH SUCKER FAN) (SUB AT51100, T52863 AND T52865)
1шт.
31C
AT51100
EXTENSION
R.H. (WITHOUT AIR CONDITIONING) (WITH BLOWER FAN)
1шт.
AT51100
EXTENSION
R.H. (WITHOUT AIR CONDITIONING) (WITH SUCKER FAN) (SUB FOR AT51099) (ALSO ORDER T52863 AND T52865)
1шт.
32
T52865
INSULATOR
(USE WITH AT51099 AND AT51100 SUCKER FAN APPLICATIONS)
1шт.
33
T52864
FOAM PAD
(USE WITH AT51099 SUCKER FAN APPLICATION)
1шт.
34
T52863
FOAM PAD
(USE WITH AT51099 AND AT51100 SUCKER FAN APPLICATIONS)
1шт.
35
T40248
PIN FASTENER
1шт.
36
T25922
WASHER
(USE IF AVAILABLE)
ARшт.
Выбрано товаров: 44
