Запчасти John Deere 90 6 - INTAKE MANIFOLD 15 - INTAKE AND EXHAUST SYSTEM

Схема запчастей John Deere 90 - 6 - INTAKE MANIFOLD 15 - INTAKE AND EXHAUST SYSTEM

Артикул

Название

Примечание

Количество

1

TY22470

CLAMP

(SUB FOR AR21840) (SUB FOR AR65293)

2шт.

2

R43604

HOSE

1шт.

3

PIPE

(SUB FOR R48975) (R43222 NO LONGER AVAILABLE)

1шт.

PIPE

( R56222 NO LONGER AVAILABLE) (SUB FOR R54886)

1шт.

4

AT37478

HOSE CLAMP

(SUB FOR AR21841 OR AR62936)

2шт.

5

R43605

HOSE

1шт.

6

R26297

GASKET

3шт.

7

AR43608

INTAKE MANIFOLD

( AR43608 NO LONGER AVAILABLE)

1шт.

R46411

INTAKE MANIFOLD

1шт.

8

19H3239

CAP SCREW

3/8" X 1-1/4"

5шт.

19H2664

CAP SCREW

5/16" X 3/4"

5шт.

9

12H304

LOCK WASHER

3/8"

6шт.

10

B1986R

CLIP

1шт.

11

15H280

PIPE PLUG

1-1/4"

1шт.

Выбрано товаров: 14
