Запчасти John Deere 90 9 - MOTOR BRAKE VALVE 45 - TRACK AND PLANETARY DRIVE

1

19H2922

SCREW

SOCKET-HEAD, 3/8" X 1-1/4"

16шт.

2

24H1301

WASHER

13/32" X 9/16" X 0.065"

16шт.

3

COVER

( U46487 NO LONGER AVAILABLE)

2шт.

4

AT264324

O-RING

(SUB FOR T32587, TH100044)

4шт.

5

U46485

SPRING

2шт.

6

HOUSING

(SUB AT32442 OR AT32443)

2шт.

AT32377

HOUSING

(NO. 1) (MATCH WITH NO. 1 ON HOUSING)

1шт.

HOUSING

(NO. 2) (MATCH WITH NO. 2 ON HOUSING) ( AT32378 NO LONGER AVAILABLE)

1шт.

AT32379

HOUSING

(NO. 3) (MATCH WITH NO. 3 ON HOUSING)

1шт.

7

WASHER

(2 SETS USED) ( AU43830 NO LONGER AVAILABLE)

1шт.

8

SPRING

(PROPELLING MOTOR) ( U46479 NO LONGER AVAILABLE)

1шт.

SPRING

(SWING MOTOR) ( U46491 USE IF AVAILABLE)

1шт.

9

U46480

O-RING

2шт.

10

U46481

BACK-UP RING

2шт.

11

ROD

(NO LONGER AVAILABLE)

1шт.

12

FITTING

( U46488 NO LONGER AVAILABLE)

2шт.

13

4506418

O-RING

(SUB FOR U46489)

2шт.

14

U46166

O-RING

2шт.

15

U46475

SPRING

2шт.

16

WASHER

(NO LONGER AVAILABLE)

1шт.

17

SPOOL

PROPELLING MOTOR, (SUB AT32442)

1шт.

SPOOL

SWING MOTOR, (SUB AT32443)

1шт.

SPOOL

(NO. 1) (MATCH WITH NO. 1 ON HOUSING) ( AT32375 USE IF AVAILABLE)

1шт.

SPOOL

(NO. 4) (MATCH WITH NO. 4 ON HOUSING) (NO LONGER AVAILABLE)

1шт.

SPOOL

(NO. 2) (MATCH WITH NO. 2 ON HOUSING) ( AT31885 NO LONGER AVAILABLE)

1шт.

SPOOL

(NO. 3) (MATCH WITH NO. 3 ON HOUSING) ( AT31886 NO LONGER AVAILABLE)

1шт.

18

HOUSING

(SUB AT32442 OR AT32443)

1шт.

19

24M7240

WASHER

13 X 25 X 3 MM

8шт.

20

19H3198

SCREW

1/2" X 3-1/4"

8шт.

AT32442

VALVE

(PROPELLING MOTOR)

1шт.

AT32443

VALVE

(SWING MOTOR)

1шт.
