Запчасти John Deere 90 8 - PROPELLING MACHINERY 45 - TRACK AND PLANETARY DRIVE

1

GAUGE

( U46151 NO LONGER AVAILABLE)

1шт.

U46150

PACKING

1шт.

2

THREADED NIPPLE

( U46149 NO LONGER AVAILABLE)

1шт.

3

CRANKCASE

( U46362 NO LONGER AVAILABLE)

1шт.

4

15H585

PIPE PLUG

SQ. HD., 3/4"

2шт.

5

15H623

PIPE PLUG

SQ. HD., 3/8"

1шт.

6

BOLT

( U46153 NO LONGER AVAILABLE)

5шт.

12H245

LOCK WASHER

7/8"

5шт.

14H852

NUT

7/8"

5шт.

7

489296

SHIM

(SUB FOR U46152)

3шт.

8

19H3126

CAP SCREW

HS, SAE 8, 3/4" X 2-1/4"

8шт.

12H236

LOCK WASHER

3/4"

8шт.

14H863

NUT

3/4"

8шт.

9

BUSHING

( U46139 NO LONGER AVAILABLE)

1шт.

10

984194

SEAL

(SUB FOR U46140)

1шт.

11

U46141

COVER

1шт.

12

U46142

WASHER

3шт.

13

19H2632

CAP SCREW

1/2" X 1-1/8"

6шт.

14

SUPPORT

(NO LONGER AVAILABLE)

1шт.

15

316566

DRIVE SPROCKET

(SUB FOR U46144)

1шт.

16

U46145

PLATE

1шт.

17

WASHER

( U46146 NO LONGER AVAILABLE)

1шт.

18

19H3617

CAP SCREW

HS, SAE 8, 7/16" X 1-1/8"

4шт.

19

U46138

SPHERICAL ROLLER BEARING

1шт.

20

U46130

SHAFT

1шт.

21

GEAR

( U46131 USE IF AVAILABLE)

1шт.
