2
12H317
Lock Washer
9/16"
8шт.
3
8037416
Bracket
SUB FOR TH108296
1шт.
4
8037415
Bracket
SUB FOR TH108297
1шт.
5
19M7403
Cap Screw
M12 X 35
4шт.
15
2021613
Manifold
SUB FOR TH108304
1шт.
17
19M8340
Screw
M10 X 65
2шт.
18
AT264324
O-Ring
SUB FOR TH100044, USE IF AVAILABLE
1шт.
AT264324
O-Ring
SUB FOR T32587, TH100044
1шт.
20
4188627
Flow Control Hyd. Valve
SUB FOR TH108305
1шт.
21
4188628
Ring
SUB FOR TH108306
1шт.
22
40M1864
Snap Ring
1шт.
23
4196287
Hose
SUB FOR AT126312
1шт.
24
TY22472
Clamp
SUB FOR AT145651 OR AR21999
2шт.
25
AT39141
Hose Clamp
SUB FOR TH108308, OR AH 104837 THIS APPLICATION
2шт.
26
8044270
Line
SUB FOR AT127129
1шт.
31
4071213
Coupling
SUB FOR TH101923 AND FXV00000005
2шт.
31A
Coupling
SUB FOR TH106965 AND 4196258
2шт.
32
4069801
Coupling
SUB FOR TH101915 AND 4712341
1шт.
32A
4196259
Seal
SUB FOR TH106966
2шт.
33
8044269
Line
SUB FOR AT127128
1шт.
34
4204745
Flow Control Hyd. Valve
SUB FOR TH109531
1шт.
38
4190127
Clamp
SUB FOR TH108313
1шт.
39
FF101775
Clamp
SUB FOR 4198598 AND AT126328
1шт.
40
19M8348
Cap Screw
M12 X 65
1шт.
42
19M8088
Cap Screw
M12 X 75
1шт.
43
24M7047
Washer
13 X 24 X 2.500 mm
1шт.
44
12M7058
Lock Washer
12 mm SUB FOR 12M7067
1шт.
64
4229940
Hyd Actuated Control Valve
SUB FOR AT126801, AT186095 AND 4229940EX
1шт.
77
4200465
Adapter Fitting
SUB FOR TH108328
2шт.
77A
M800650
Packing
1шт.
80
19M7877
Cap Screw
M14 X 30
8шт.
83
4086891
Washer
SUB FOR TH104166
2шт.
86
M341022
Screw
SUB FOR TH105695
2шт.
87
19M8339
Screw
M10 X 55
4шт.
88
4203137
O-Ring
SUB FOR TH108310
1шт.
94
AH99745
Hydraulic Hose
1шт.
