Артикул
Название
Примечание
Количество
0
9141367
Lift Arm
(SUB FOR TH9141367)
1шт.
0B
4297643
Stop
(SUB FOR TH4297643)
1шт.
0C
4297750
Stop
(SUB FOR TH4297750)
1шт.
0D
3060580
Bushing
(SUB FOR TH3060580)
2шт.
0F
3079228
Bushing
(SUB FOR TH3079228)
2шт.
0G
4295981
Bushing
(SUB FOR TH4295981)
2шт.
4
Hydraulic Cylinder
Bucket See Separate Page For Detail
1шт.
5
9111926
Link
(SUB FOR TH9111926)
1шт.
5B
3060583
Bushing
(SUB FOR TH3060583)
2шт.
5C
3060582
Bushing
(SUB FOR TH3060582)
2шт.
5F
TH100074
Lubrication Fitting
2шт.
6
8049555
Link
(SUB FOR TH8049555)
1шт.
7
8050377
Link
(SUB FOR TH8050377)
1шт.
11
8053519
Pin Fastener
(SUB FOR TH8053519)
2шт.
13
AT318057
Pin Fastener
(SUB FOR 3060596, TH3060596)
1шт.
14
3097975
Pin Fastener
(SUB FOR TH3060595 AND 3060595)
1шт.
15
AT318058
Pin Fastener
(SUB FOR 3079227, TH3079227)
1шт.
16
AT318054
Pin Fastener
(SUB FOR 3052361, TH3052361)
1шт.
17
TH100074
Lubrication Fitting
6шт.
20
4295167
Cap Screw
(SUB FOR TH4295167)
4шт.
22
4122729
Strap
(SUB FOR AT131696)
2шт.
23
12M7070
Lock Washer
20 mm
4шт.
24
19M7950
Cap Screw
M20 X 45
4шт.
28
4130686
Bushing
(SUB FOR AT217082)
2шт.
29
4105912
Cap
(SUB FOR AT217081)
2шт.
33
4296540
Shim
(SUB FOR TH4296540)
1шт.
38
AT202135
Hydraulic Hose
2шт.
40
19M8395
Screw
M12 X 40
8шт.
41
T78313
O-Ring
32.920 X 3.530 mm (1.296" X 0.139")
2шт.
50
AT188459
Arm
Includes Arm, Bucket Cyl inder, Hoses and Linkage
1шт.
Выбрано товаров: 39
