Запчасти John Deere 0ZTS 197 - TWO WAY MULTI-LEVER VALVE 3360 HYDRAULIC SYSTEM

0

4460294

Flow Control Hyd. Valve

SUB FOR AT258398; SUB FOR TH4460294

1шт.

1

19M8011

Cap Screw

M12 X 30

4шт.

12M7058

Lock Washer

12 mm SUB FOR 12M7067

4шт.

4

4408091

Bushing

SUB FOR AT258387

1шт.

7

4395013

Bracket

SUB FOR AT258373

1шт.

8

8070708

Bracket

SUB FOR AT258440

1шт.

9

19M7402

Cap Screw

M10 X 25

3шт.

24M7096

Washer

10.500 X 18 X 1.600 mm

3шт.

12M7066

Lock Washer

10 mm

3шт.

10

4401287

Hose Guard

SUB FOR AT258379

1шт.

14

19M7407

Cap Screw

M8 X 25

2шт.

24M7055

Washer

8.400 X 16 X 1.600 mm

2шт.

Washer

12M7065 NLA

2шт.

17

AT158446

Piston

1шт.

18

2044813

Label

SUB FOR AT258317

1шт.

24

4351893

Wrench

SUB FOR AT258337

1шт.
