Запчасти John Deere 0ZTS 157 - Oil Cooler Piping 3360 HYDRAULIC SYSTEM

1

4414503

Elbow Fitting

SUB FOR AT251504

1шт.

1A

4506418

O-Ring

17.800 X 2.400 mm (0.701 " X 3/32") SUB FOR U46489

1шт.

14

4037760

Elbow Fitting

SUB FOR AT251156

1шт.

14A

4506418

O-Ring

17.800 X 2.400 mm (0.701 " X 3/32") SUB FOR U46489

1шт.

15

4368222

Tee Fitting

SUB FOR AT251305

1шт.

15A

4506418

O-Ring

17.800 X 2.400 mm (0.701 " X 3/32") SUB FOR U46489

1шт.

16

M800462

Plug

1шт.

17

4399568

Bracket

SUB FOR AT251414

1шт.

18

19M7407

Cap Screw

M8 X 25

2шт.

24M7055

Washer

8.400 X 16 X 1.600 mm

2шт.

Washer

12M7065 NLA

2шт.

21

8077347

Oil Line

SUB FOR AT251604

1шт.

22

4396502

Spacer

SUB FOR AT251392

4шт.

23

19M7165

Cap Screw

M8 X 55

4шт.

24M7055

Washer

8.400 X 16 X 1.600 mm

4шт.

Washer

12M7065 NLA

4шт.

24

4391982

Clamp

SUB FOR AT251328

2шт.

25

4391983

Bracket

SUB FOR AT251329

2шт.

26

9753257

Oil Line

SUB FOR AT251652

1шт.

27

4398260

Clamp

SUB FOR AT251401

2шт.

28

9753258

Oil Line

SUB FOR AT251653

1шт.

29

4374981

Clamp

SUB FOR AT251311

2шт.

30

19M7932

Cap Screw

M8 X 16

2шт.

24M7055

Washer

8.400 X 16 X 1.600 mm

2шт.

Washer

12M7065 NLA

2шт.

32

R50454

Clamp

SUB FOR 4295017, AT251218 OR 4411911

1шт.

33

TCU15362

Isolator

SUB FOR AT251319 OR 4387596

1шт.

34

19M7932

Cap Screw

M8 X 16

1шт.

24M7055

Washer

8.400 X 16 X 1.600 mm

1шт.

Washer

12M7065 NLA

1шт.

38

4408125

Adapter Fitting

SUB FOR AT251455

2шт.

38A

4506418

O-Ring

17.800 X 2.400 mm (0.701 " X 3/32") SUB FOR U46489

1шт.

39

4368204

Adapter Fitting

SUB FOR AT251299

1шт.

39A

4506418

O-Ring

17.800 X 2.400 mm (0.701 " X 3/32") SUB FOR U46489

1шт.

73

4426434

Hydraulic Hose

SUB FOR AT251661

1шт.

74

4426435

Hydraulic Hose

SUB FOR AT251662

1шт.

75

4426436

Hydraulic Hose

SUB FOR AT251663

1шт.

78

4426438

Hydraulic Hose

SUB FOR AT251664

1шт.

79

4426437

Hydraulic Hose

SUB FOR AT251665

1шт.

80

4426439

Hydraulic Hose

SUB FOR AT251666

1шт.
