Запчасти John Deere 95D 66 - INDEPENDENT STABILIZER HYDRAULIC HOSES AND LINES 3360 - EXCAVATOR 33

1

CONTROL VALVE

(SUB AT130824) ( AT126343 NO LONGER AVAILABLE)

1шт.

4263455

HYD ACTUATED CONTROL VALVE

(SUB FOR AT126343) (SUB FOR AT130824)

1шт.

32

8043181

SUPPORT

(SUB FOR AT134282)

1шт.

33

19M8011

CAP SCREW

M12 X 30

2шт.

34

19M7403

CAP SCREW

1шт.

35

24M7047

WASHER

13 X 24 X 2.500 MM

3шт.

36

12H301

LOCK WASHER

1/2"

3шт.

37

19M8547

SCREW

M12 X 90, (SUB FOR AT127258 OR M341290)

3шт.

41

4203163

TEE FITTING

(SUB FOR AT126355)

2шт.

41A

M800650

PACKING

1шт.

45

AE24616

ELBOW FITTING

(SUB FOR AT128481, ALONG WITH AH89069) (SUB FOR AT134106, ALONG WITH AH89069)

1шт.

46

AH89069

ELBOW FITTING

1шт.

50

AT134108

HYDRAULIC HOSE - FABRICATE

2шт.

51

T77857

O-RING

(SUB FOR TH108323)

8шт.

52

4217341

ELBOW FITTING

(SUB FOR AT126684)

6шт.

52A

AT318035

O-RING

(SUB FOR 4506424, TH100055)

1шт.

53

AT134109

HYDRAULIC HOSE

13/16" X 1 100 MM (43-1/4") X 13/16"

2шт.

54

AT134110

HYDRAULIC HOSE - FABRICATE

13/16" X 900 MM (35-1/2") X 13/16"

1шт.

55

AT134077

HYDRAULIC HOSE - FABRICATE

13/16" X 950 MM (37-1/2") X 13/16"

1шт.

56

4189602

FITTING

(SUB FOR TH108350)

1шт.

56A

4506418

O-RING

(SUB FOR U46489)

1шт.

57

4205383

TEE FITTING

(SUB FOR AT134051)

1шт.

57A

4506418

O-RING

(SUB FOR U46489)

1шт.

58

R69667

O-RING

2шт.

65

4202103

CLAMP

(SUB FOR TH108302)

1шт.

66

9727633

CLAMP

(SUB FOR TH108303)

1шт.

67

19M7363

CAP SCREW

M12 X 60

1шт.

68

24M7047

WASHER

13 X 24 X 2.500 MM

1шт.

69

12H301

LOCK WASHER

1/2"

1шт.

70

14M7275

NUT

M12

1шт.

85

4189602

FITTING

(SUB FOR TH108350)

1шт.

85A

4506418

O-RING

(SUB FOR U46489)

1шт.

86

T77857

O-RING

(SUB FOR TH108323)

2шт.
