1
8075450
Lever
(SUB FOR AT174467, 8062667)
1шт.
2043585
Grip
Not Illustrated
1шт.
4424185
Nut
Not Illustrated
1шт.
2
8075449
Lever
(SUB FOR AT174468 OR 8062623)
1шт.
2043584
Grip
Not Illustrated
1шт.
4424185
Nut
Not Illustrated
1шт.
12
9149235
Hyd Actuated Control Valve
(SUB FOR AT214393) Pilot
1шт.
14
24M7028
Washer
10.500 X 20 X 2 mm
2шт.
15
19M8337
Screw
M10 X 30
2шт.
17
12M7066
Lock Washer
10 mm
2шт.
18
T205603
Bracket
(SUB FOR AT174469 OR 3072628)
2шт.
19
34M7062
Spring Pin
5 X 32 mm
2шт.
20
34M7124
Spring Pin
8 X 30 mm (SUB FOR 34M7065)
2шт.
25
2038735
Grip
(SUB FOR AT213747)
1шт.
26
2038734
Grip
(SUB FOR AT213746)
1шт.
28
1024384
Pedal
(SUB FOR AT202292)
1шт.
29
1024224
Pedal
(SUB FOR AT202291)
1шт.
30
19M7935
Cap Screw
M10 X 55
4шт.
41
1015478
Footrest
(SUB FOR AT154056)
1шт.
42
1015477
Footrest
(SUB FOR AT154055)
1шт.
43
3052543
Cover
(SUB FOR AT154127)
2шт.
45
19M7550
Cap Screw
M10 X 35
8шт.
12M7066
Lock Washer
10 mm
8шт.
