Запчасти John Deere 5ZTS 154 - OIL COOLER PIPING 3360 HYDRAULIC SYSTEM

1

4416475

Tee Fitting

(SUB FOR TH4416475)

2шт.

1A

4506418

O-Ring

17.800 X 2.400 mm (0.701" X 3/32") (SUB FOR U46489)

1шт.

16

4368222

Tee Fitting

(SUB FOR AT251305)

1шт.

16A

4506418

O-Ring

17.800 X 2.400 mm (0.701" X 3/32") (SUB FOR U46489)

1шт.

17

M800462

Plug

3шт.

47

4419501

Fitting

(SUB FOR TH4419501)

2шт.

47A

CH11570

O-Ring

13.800 X 2.400 mm (0.543" X 3/32")

1шт.

53

4042031

Adapter Fitting

(SUB FOR TH103891)

1шт.

53A

CH11570

O-Ring

13.800 X 2.400 mm (0.543" X 3/32")

1шт.

60

4428030

Hydraulic Hose

(P1) (SUB FOR TH4428030)

1шт.

61

4428031

Hydraulic Hose

(P2) (SUB FOR TH4428031)

1шт.

62

4428032

Hydraulic Hose

(P3) (SUB FOR TH4428032)

1шт.

74

4432868

Sleeve

(SUB FOR TH4432868)

3шт.

75

4432872

Cover

(SUB FOR TH4432872)

1шт.

76

21M7192

Screw

M8 X 16

2шт.

77

4363181

Socket

1шт.
