Запчасти John Deere 5ZTS 80 - SEAT BASE 1821 SEAT AND SEAT BELT

1

6018817

Support

(SUB FOR TH6018817)

1шт.

7

4435169

Isolator

(SUB FOR TH4435169)

1шт.

10

19M7402

Cap Screw

M10 X 25

4шт.

24M7096

Washer

10.500 X 18 X 1.600 mm

4шт.

12M7066

Lock Washer

10 mm

4шт.

11

4377301

Isolator

(SUB FOR TH4377301)

1шт.

14

8078297

Cover

(SUB FOR TH8078297)

1шт.

15

19M7881

Screw

M8 X 20

4шт.

24M7055

Washer

8.400 X 16 X 1.600 mm

4шт.

12M7056

Lock Washer

8 mm

4шт.

18

8078296

Cover

(SUB FOR TH8078296)

1шт.

19

J090612

Bolt

(SUB FOR AP34403)

4шт.

21

4423918

Lock

(SUB FOR AT251525)

1шт.

22

4423917

Isolator

(SUB FOR TH4423917)

1шт.

26

19M8011

Cap Screw

M12 X 30

4шт.

24M7044

Washer

13 X 20 X 2 mm

4шт.

12M7058

Lock Washer

12 mm

4шт.

28

4438882

Bracket

(LEFT) (SUB FOR TH4438882)

1шт.

29

4438883

Bracket

(RH)

1шт.
