1
R29424
Flange Fitting
(SUB FOR 986910)
6шт.
5
T59014
O-Ring
(SUB FOR 971489)
3шт.
6
19M7576
Screw
M10 X 30 (SUB FOR J781030)
12шт.
8
966993
O-Ring
1шт.
13
19M8166
Cap Screw
M10 X 110 (SUB FOR 4282721)
2шт.
24M7028
Washer
10.500 X 20 X 2 mm
2шт.
12M7066
Lock Washer
10 mm
2шт.
14
19M7402
Cap Screw
M10 X 25 (SUB FOR J021025)
4шт.
12M7066
Lock Washer
10 mm
4шт.
24M7028
Washer
10.500 X 20 X 2 mm
4шт.
17
9756369
Oil Line
1шт.
19
J781035
Bolt
4шт.
24
4454729
Spacer
2шт.
25
8084181
Bracket
1шт.
26
8084182
Bracket
1шт.
27
3092170
Isolator
1шт.
28
3092171
Isolator
1шт.
33
T76938
O-Ring
(SUB FOR 4187238)
1шт.
34
H77698
Tie Band
7шт.
35
Hydraulic Hose
( 9205398 NLA)
1шт.
35A
4457577
Hydraulic Hose
1шт.
35B
Hose Guard
(MAKE FROM XHG-075 , CUT TO LENGTH) ( 4327294 NLA)
3шт.
36
Hydraulic Hose
( 9205399 NLA)
1шт.
36A
4457574
Hydraulic Hose
1шт.
36B
Hose Guard
(MAKE FROM XHG-075 , CUT TO LENGTH) ( 4327294 NLA)
3шт.
37
Hydraulic Hose
( 9205396 NLA)
1шт.
37A
4457578
Hydraulic Hose
1шт.
37B
Hose Guard
(MAKE FROM XHG-075 , CUT TO LENGTH) ( 4327294 NLA)
3шт.
38
Hydraulic Hose
( 9205400 NLA)
1шт.
38A
4457567
Hydraulic Hose
1шт.
38B
Hose Guard
(MAKE FROM XHG-075 , CUT TO LENGTH) ( 4327294 NLA)
3шт.
