Запчасти John Deere 35D 142 - COOLING PACKAGE AND HYDRAULIC PUMP COMPARTMENT DOORS (TROPICAL) 1910 HOOD OR ENGINE ENCLOSURE

1

7040807

Door

Assembly

1шт.

1A

Door

( 6020273 NLA)

1шт.

1B

4409446

Lock

Weld In

1шт.

DH400030

Latch

Rivet In

1шт.

1C

4447105

Isolator

1шт.

1D

4447027

Isolator

1шт.

2

7040813

Door

Assembly

1шт.

2A

Door

( 6020272 NLA)

1шт.

2B

4409394

Lock

1шт.

4

24M7028

Washer

10.500 X 20 X 2 mm (SUB FOR A590110)

8шт.

5

12M7066

Lock Washer

10 mm (SUB FOR A590910)

8шт.

6

14M7274

Nut

M10 (SUB FOR J950010)

8шт.

8

4341788

Rod

(SUB FOR 4341788J)

2шт.

9

24M7055

Washer

8.400 X 16 X 1.600 mm (SUB FOR A590108)

2шт.

10

H132922

Cotter Pin

(SUB FOR 4022697)

2шт.
