1
8973148952
Hydraulic Pump
(SUB FOR 8973148951)(COMP ONENTS ON A ANOTHER PAGE)
3шт.
2
14M7298
Flange Nut
M8 (SUB FOR AT195658, AT259945 OR 4447338)
6шт.
3
19M7866
Screw
M8 X 20 (SUB FOR AT259925)
6шт.
4
8972283851
Line
(SUB FOR 8972283850)
3шт.
5
R56101
Clip
(SUB FOR AT254829 AND AT 261421)( 1097070870 NLA)
3шт.
6
8972292513
Hose
1шт.
7
8944337171
Bolt
3шт.
8
8971952593
Bracket
(SUB FOR 8971952590 OR 8971952591)
1шт.
9
8972293672
Nozzle
(COMPONENTS ON A ANOTHER PAGE)
3шт.
10
8972172470
Line
1шт.
11
8971713310
Gasket
3шт.
12
8943264390
Gasket
3шт.
13
8943796880
Bolt
3шт.
14
8941445880
Gasket
6шт.
15
8972289040
Line
(SUB FOR AT261306)
1шт.
16
8972272821
Shim
0.2MM (.008 IN.)
ARшт.
8972272831
Shim
0.3MM (.012 IN.)
ARшт.
8972272841
Shim
0.4MM (.016 IN.)
ARшт.
8972272851
Shim
0.5MM (.020 IN.)
ARшт.
8972272861
Shim
0.6MM (.024 IN.)
ARшт.
8972272871
Shim
0.7MM (.028 IN.)
ARшт.
8972272881
Shim
0.8MM (.031 IN.)
ARшт.
8972272891
Shim
0.10MM (.039 IN.)
ARшт.
8972272901
Shim
0.12MM (.047 IN.)
ARшт.
