Запчасти John Deere 554 36 - Fuel Injection System 0413 Fuel Injection System

1

8973148952

Hydraulic Pump

(COMPONENTS ON ANOTHER PAGE)

4шт.

2

19M7866

Screw

M8 X 20 (SUB FOR AT259925)M8 X 20 FLANGE

8шт.

3

8973148971

Nozzle

(COMPONENTS ON ANOTHER PAGE)

4шт.

4

8972323341

Gasket

4шт.

5

R56101

Clip

(SUB FOR AT261421 ) (SUB FOR 10970 70870)ID=11 MM, (SUB FOR AT254829)

2шт.

6

8944337171

Bolt

4шт.

7

Bulk Hose

(SUB BULK AS REQUIRED)

1шт.

8

8971952593

Bracket

(SUB FOR 8971952590 OR 8971952591)

4шт.

9

8972172492

Line

1шт.

10

8943264390

Gasket

ALSO INCLUDED IN ENGINE GASKET SET

4шт.

11

8971713310

Gasket

4шт.

12

8972283851

Line

(SUB FOR 8972283850)

4шт.

13

8971920980

Line

1шт.

14

14M7298

Flange Nut

M8 (SUB FOR 0911502080 OR 14M7298)M8 FLAN GE, (SUB FOR AT195658) (SUB FOR AT259945)

8шт.

15

8972272821

Shim

T=0.2 MM

ARшт.

8972272831

Shim

T=0.3 MM

ARшт.

8972272841

Shim

T=0.4 MM

ARшт.

8972272851

Shim

T=0.5 MM

ARшт.

8972272861

Shim

T=0.6 MM

ARшт.

8972272871

Shim

T=0.7 MM

ARшт.

8972272881

Shim

T=0.8 MM

ARшт.

8972272891

Shim

T=1.0 MM

ARшт.

8972272901

Shim

T=1.2 MM

ARшт.
