Запчасти John Deere 30LC/370 317 - BOOM CYLINDER LOAD LOWERING VALVE KIT 3360 HYDRAULIC SYSTEM

1

Kit

AT184298 NO LONGER AVAILABLE (BOOM CYLI NDER LOAD LOWERING VALVE) (CONTAINS ALL I TEMS ON THIS PAGE - ADDITIONAL COMPONENTS LISTED ON PREVIOUS AND FOLLOWING PAGES)

1шт.

2

8071036

Clamp

SUB FOR AT184314

1шт.

3

8071035

Clamp

SUB FOR AT184317

1шт.

4

8071060

Oil Line

SUB FOR AT184319

1шт.

5

Hose Guard

MAKE FROM XHG-075, BULK MATERIAL, CUT TO LENGTH SUB FOR AT213832, 4327294 NLA

3шт.

6

AT174563

Hydraulic Hose

1-1/16" X 1200 mm (47-1/4") X 1-1/16"

1шт.

7

8071059

Oil Line

SUB FOR AT184316

1шт.

8

4154670

Elbow Fitting

SUB FOR TH100951

3шт.

9

4205363

Tee Fitting

SUB FOR AT126362

1шт.

10

AT184322

Hydraulic Hose

11.1252" X 1500 mm (59") X 11.1252"

1шт.

4327315

Hose Guard

4327293 NO LONGER AVAI LABLE SUB FOR AT213831

3шт.

11

AT184323

Hydraulic Hose

11.1252" X 1550 mm (61") X 11.1252"

1шт.

4327315

Hose Guard

4327293 NO LONGER AVA ILABLE SUB FOR AT213831

3шт.

12

AT184321

Hydraulic Hose

9/16" X 2900 mm (114-1/4") X 9/16"

1шт.

4327315

Hose Guard

4327293 NO LONGER AVAI LABLE SUB FOR AT213831

7шт.

13

AT184320

Hydraulic Hose

1-1/16" X 2950 mm (116-1/4") X 1-1/16"

1шт.

Hose Guard

MAKE FROM XHG-075, BULK MATERIAL CUT T O LENGTH SUB FOR AT213832, 4327294 NLA

9шт.

14

AT184320

Hydraulic Hose

1-1/16" X 2950 mm (116-1/4") X 1-1/16"

1шт.

Hose Guard

MAKE FROM XHG-075, BULK MATERIAL CUT T O LENGTH SUB FOR AT213832, 4327294 NLA

9шт.

15

8074717

Line

SUB FOR AT184311

1шт.

16

4288001

Adapter Fitting

SUB FOR AT184312

2шт.

17

4226388

Tee Fitting

SUB FOR AT205878

1шт.
