Артикул
Название
Примечание
Количество
0
9156582
Valve
NLA (ORDER 9156582EX)
2шт.
9156582EX
Hyd/Pilot Cntl Valve Reman
(USE AT214396 IF AVAILABLE) (FRONT AND SWING) (REMAN FOR 9156582) (SU B FOR AT214396 ) (SUB FOR AT189844)
2шт.
1
4201915
Spring
(SUB FOR TH109212)
2шт.
2
4166686
Compression Spring
(SUB FOR TH109213)
2шт.
3
4195421
Compression Spring
(SUB FOR TH109214)
2шт.
4
4379022
Compression Spring
(SUB FOR AT215558)
2шт.
5
4177777
Spacer
(SUB FOR AT154411 ) (SUB FOR TH109216)
4шт.
6
4173208
Shim
(SUB FOR TH109217)
20шт.
7
4177896
Guide
(SUB FOR TH109218)
2шт.
8
4179257
Guide
(SUB FOR AT154412 ) (SUB FOR TH109219)
2шт.
10
Housing
(SUB FOR AT214342)( 7031409 NLA)
1шт.
11A
Bushing
(NOT AVAILABLE FOR SERVICE)
1шт.
11C
U46166
O-Ring
24.400 X 3.100 mm (0.961" X 0.122")
1шт.
12A
Bushing
(NOT AVAILABLE FOR SERVICE)
1шт.
12C
U46166
O-Ring
24.400 X 3.100 mm (0.961" X 0.122")
1шт.
15
4184929
Piston
(SUB FOR TH109228)
4шт.
16
4286874
Sealing Washer
(SUB FOR AT155701)
1шт.
17
CH11571
Packing
1шт.
18
4184954
Plate
(SUB FOR TH109229)
1шт.
19
19M8168
Screw
M12 X 25
1шт.
24
4285209
Universal Joint
(SUB FOR TH109230)
1шт.
27
4182067
Jointer
(SUB FOR TH109232)
1шт.
Выбрано товаров: 26
