Запчасти John Deere 7ZTS 156 - Oil Cooler Piping 3360 HYDRAULIC SYSTEM

1

4416475

Tee Fitting

(SUB FOR TH4416475)

2шт.

1A

4506418

O-Ring

17.800 X 2.400 mm (0.701" X 3/32") (SUB FOR U46489)

1шт.

16

4368222

Tee Fitting

(SUB FOR AT251305)

1шт.

16A

4506418

O-Ring

17.800 X 2.400 mm (0.701" X 3/32") (SUB FOR U46489)

1шт.

17

M800462

Plug

3шт.

47

4419500

Adapter Fitting

(SUB FOR TH4419500)

2шт.

47A

CH11570

O-Ring

13.800 X 2.400 mm (0.543" X 3/32")

1шт.

48

4368210

Adapter Fitting

(SUB FOR AT251302)

1шт.

48A

CH11570

O-Ring

13.800 X 2.400 mm (0.543" X 3/32")

1шт.

60

4427890

Hydraulic Hose

(P3) (SUB FOR TH4427890)

1шт.

66

4438904

Hydraulic Hose

(SUB FOR TH4438904)(P1)

1шт.

67

4438905

Hydraulic Hose

(SUB FOR TH4438905)(P2)

1шт.

68

4421006

Hose Guard

(SUB FOR TH4421006)

3шт.

70

4432872

Cover

(SUB FOR TH4432872)

1шт.

71

21M7192

Screw

M8 X 16

2шт.

73

4430923

Hose Guard

(SUB FOR TH4430923)

2шт.

75

R50454

Clamp

(SUB FOR 4295017, AT251218 OR 4411911)

2шт.

76

TCU15362

Isolator

(SUB FOR AT251319 OR 4387596)

2шт.

77

19M7932

Cap Screw

M8 X 16

2шт.

24M7055

Washer

8.400 X 16 X 1.600 mm

2шт.

12M7056

Lock Washer

8 mm

2шт.
